Specifications
Brand Name :
Shenzhen LED World
Model Number :
LW-FO 6 , 8
Certification :
CE,RoHS,FCC,CCC
Place of Origin :
China
MOQ :
1 square meter
Price :
negotiable
Payment Terms :
T/T, Western Union, MoneyGram
Supply Ability :
5,000 square meters per month
Delivery Time :
10~20 days after receiving the deposit
Packaging Details :
Carton/Plywood case etc.
Driving Method :
Constant Current Driving
Power Supply Mode :
5V/40A
Working Voltage(V) :
AC220V±10%
P6 Size of Module(mm) :
192x192mm
LED Encapulation :
SMD3535
Level of Brightness/Color :
rgb256
p6 Scan and control Method :
1/8 Synchronous Control
Driving Components :
Constant current Driving
Description

Outdoor series fixed led display_201905211506521.p...SMD3535 P6 , P8 Outdoor Fixed LED screen panel board with WIFI Commercial

P6 , P8 Outdoor LED screen panel board features:

  • High protection grade of IP65 achieved by patented mask design with waterproof and dustproof function;
  • Brilliant colors, breathtaking grayscales;
  • Real white, brilliant colors, breathtaking grayscale;
  • Cabinet structure is easy to install and deliver；
  • Simple and beautiful design;
  • Higher density, higher resolution and more clear & stable picture displaying;

P6 , P8 Outdoor LED screen panel board​ parameter:

Module Parameter NO. P6 P8
Size of Module(mm) 192*192 256*128
Pixel Density(dots/m²) 27777 dots/m² 15625 dots/m²
Pixel Pitch(mm) 6mm 8mm
LED Encapulation SMD3535 SMD3535
Resolution of Module(dots) 32(W)*32(H) 32(W)*16(H)
Thickness of Module (mm) 17.05(No magnet) 17.05(No magnet)
Weight of Module (Kg) 0.369 0.343
Driving Method Constant Current Driving Constant Current Driving
Equilibrium Brightness(CD//m²) ≥7000 CD/m² ≥6500 CD/m²
Bracket Size(mm) 192*192 256*128
384*192 256*256
Cabinet Size of Cabinet(mm) 576*576 768*768
512*512
Power Supply Mode 5V/40A*1PC 5V/40A*1PC
Best Viewing Distance(m) 6-100m 8-100m
Best Viewing Angle 160(W) 120(H) 160(W) 120(H)
Storage Temperature(ºC) -35ºC ~ +85ºC -35ºC ~ +85ºC
Working Temperature(ºC) -40ºC ~ +50ºC -40ºC ~ +50ºC
Relative Humidity 10%-95% 10%-95%
Power Supply Working Voltage(V) AC220V±10% AC220V±10%
Average Power Consumption(W/m²) ≤500 W/m² ≤380 W/m²
Max Consumption(W/m²) ≤1000 W/m² ≤760 W/m²
Control System Scan and control Method 1/8 Synchronous Control 1/4 Synchronous Control
Driving Components Constant current Driving Constant current Driving
Technical Parameters Refresh Frequency ≥600 Hz/Sec ≥600 Hz/Sec
(HZ)
　
Frame Frequency ≥60 HZ/Sec ≥60 HZ/Sec
(HZ)
Level of Brightness/Color RGB256 RGB256
Level of Gray 65536 65536
Notes: Specifications are for reference only. Please contact our salesperson for details. All rights are reserved to Led World.

Why choose us:

  • Good quality by using Nationstar led lamp, MBI IC;
  • Top quality + reasonable price + patient after-sales service;
  • OEM service;
  • Quick response: replying inquiry within 12hrs;
  • Quality insuranc PCIC;
  • Good service whenever;

​Our service:

  • Factory visiting and inspecting is welcome;
  • All of our led display have proceeded aging test before shipment;
  • Guarantee
  • (1) We guarantee all our displays, modules, parts for 2 - 5 full year. During this time, we will replace or remand our goods for free if there is something wrong with them.
  • (2) We will provide maintenance for a lifetime and charge for the raw materials only.
  • Protection of your sales area, ideas of design and all your private information;
  • maintainance Free:if you find the product has any problems ,pls kindly contact me;


P6 , P8 Outdoor LED screen panel board​ package detail:
SMD3535 P6 P8 Outdoor Fixed LED Screen Panel Board With WIFI Commercial
