Specifications
Brand Name :
Shenzhen LED World
Model Number :
LW-FO 6
Certification :
CE,RoHS,FCC,CCC
Place of Origin :
China
MOQ :
1 square meter
Price :
negotiable
Payment Terms :
T/T, Western Union, MoneyGram
Supply Ability :
5,000 square meters per month
Delivery Time :
10~20 days after receiving the deposit
Packaging Details :
Carton/Plywood case etc.
Operating Humidity :
10% - 90%
Pixels/Module :
32x16 or 32x32
Pixel Density :
27,777
Model No :
LW-FO 6
Configuration :
SMD3535
Supply Voltage :
AC220V/50HZ; AC110V/60HZ
Cabinet Material :
Cold Rolled Steel
LED Life :
100,000 hours
Description

Application:

mansion video wall,TV Shows,lottery center,Showrooms,government,high-speed rail station,
Sports events,grogshop,Campus,restaurant,live meeting,athletic contest,pharmacy,Airport,stage renting,enterprises,waiting room of station,public facilities,stage background,Auto Parts and Maintenance shops,cinema,parking garage,Sports Stadium and so on .

Features:

  • Superb brightness and color uniformity and reproduction. Brightness varaiances within+/-2.5%;
  • Width and height can be added endlessly as for fixed installation;
  • Easy for installation;
  • Classical and stable structure and performance;
  • Refresh rate up to 4,200Hz, completely flickering-free for live videos;
  • Support any format of video;
  • 120°horizontal/vertical viewing angle, perfect for outdoor advertisement;
  • Extremely weather-proof, adapt to different kinds of environment;
  • With the best LED industrial waterproof and ultraviolet-proof;

Parameter:

Items Parameter
Model No LW-FO 6
Pixel 1R1G1B
Configuration SMD3535
Brightness >6000cd/㎡
Pixel Pitch 6mm
Pixel Density 27,777
Driver Mode 1/4 scan or 1/8
Module Size(mm) 192x96or 192x192
Pixels/Module 32x16 or 32x32
Cabinet Size(mm) 960x960 mm or customized
Pixels/Cabinet 160x160
Cabinet Weight 36KG
Viewing Distance >6m
Power Max: 1300
Consumption(W/㎡) Ave: 260
Viewing Angle H: 120°; V: 120°
Cabinet Material Cold Rolled Steel
Refresh Rate 300-3000HZ adjustable
LED Life 100,000 hours
Supply Voltage AC220V/50HZ; AC110V/60HZ
Operating Temperature -20℃ ~ +50℃
Operating Humidity 10% - 90%
Gray Scale Red, Green and Blue each 16K
Display Color 4096 Billion
IP Rating Front IP65,back IP54
Display Capability Text, Graph and Video
Compliant Standard CE,RoHS,FCC
Notes: Specifications are for reference only. Please contact our salesperson for details. All rights are reserved to Led World.

Our company:

Shenzhen LED World Optoelectronics Limited is the top professional LED Display manufacturer, and has about 9 years experience in LED screen industry, more than 9000sqm workshop, 400 workers, automatic production line, strong R&D team. Our products have passed RoHS, 3C, FCC and CE quality authentication.
Our company offers user-friendly products that optimize productivity and business efficiency and maintain the highest standards of design and quality.
Shenzhen LED World co.,ltd will be committing to provide more cost-effective, more energy-efficient, and greener LED optoelectronic products, contributing to building a green home.
Shenzhen LED World co.,ltd consistent source of strength for the customer is the company's growth and expansion, the company has the perfect pre-sale tracking service system and truly customer -centric marketing module.
