P1.536 Ultra High Definition LED Display good uniformity smd1010 LED video wall
Features:
- High density, high definition and high refresh rate up to 3000Hz;
- 4:3 design. Cabinet's 4:3 resolution is specialized for command center. Perfect replacement for LCD display;
- Billion level color and high brightness quality black LED,realizing perfect of gray scale and contrast;
- Driver IC SUM2032/MBI 5153 Grey Scale ≥16Bit(depending on the system and IC configuration);
- Black led lamp body, high contrast rate, high definition up 1080P;
- Most competitive price for the same model in the market;
- High-Precision;
- High pixel density, High definition, Good display vision;
- It's designed for high end market,can show extremely clear video, images and texts;
- High Refresh Rate.
Parameter:
| No. | Parameter | Specification |
| 1 | Pixel Pitch(mm) | 1.536 |
| 2 | Pixel Density | 409600pix/m2 |
| 3 | LED Type | SMD1010 |
| 4 | LED Wave Length(nm) | R:620-625/G:517.5-520/B:465-467.5 |
| 5 | LED Luminous Intensity(mcd) | R:100~130/G:120~156/B:20~26 |
| 6 | Viewing Angle | 140° |
| 7 | Brightness | 1000cd/ |
| 8 | Drive Method | 1/32 scan |
| 9 | Driving IC | SUM 2017 |
| 10 | Color Depth | 16bit |
| 11 | Refresh Rate(Hz) | 2000 |
| 12 | Frame Rate(Hz) | ≥60 |
| 13 | Brightness Adjustment | Manual/Auto/Program |
| 14 | Module Size(mm) | 200×150 |
| 15 | Module Resolution() | 128×96 |
| 16 | Cabinet Size(mm) | 400×300 |
| 17 | Cabinet Display Resolution() | 256×196 |
| 18 | Cabinet Type and Material | Die-casting Aluminum |
| 19 | Cabinet Weight(Kg) | 5.6kg |
| 20 | Power Supply | 5.0V 40A |
| 21 | Voltage(V) | AC 220V |
| 22 | Avg. Power Consumption | 350W/ |
| 23 | Max. Power Consumption | 1000W/ |
| 24 | Service Access | Back maintenance |
| 25 | IP Grade | IP31 |
| 26 | Operating Temp/Humidity | -20ºC~50ºC, 10~90%RH |
| 27 | Storage Temp/Humidity | -40ºC~60ºC, 10~90%RH |
| 28 | Lifetime(Normal Temp) | ≥50000H |
| 29 | System Control | Nova/Linsn |
| 30 | Compliant Standard | CCC,CE,RoHs |
| Notes: Specifications are for reference only. Please contact our salesperson for details. All rights are reserved to Led World. |
Our service:
- You can replace the broken one with the spare parts when problem happens, which will take about 5 minutes, and then send the broken ones back to our factory for fixing freely before you don't have enough spare parts for next maintenance;
- We promise a life time follow-up service for all the equipment supply by our company. These include continuously improve of system functions and upgrade of system software;
- 1% spare parts offered FOC;
- Monthly production capacity: 3000 Sq. M;
- Delivery time: 10-25 days after receiving the deposit;
- We offered software customization for our your specific usage;
- Training in our factory offered FOC;
- We provide free maintenance services including remote configuration, technical consultation, and trouble shooting for you;
Why choose us:
- Top quality + reasonable price + patient after-sales service;
- Manufacturer: over 9 years;
- CE,RoHS,FCC, ISO9001;
- On time delivery + patient after-sales service;
- Price Advantage: We have the best competitive price at the market, also have the same even better quality;
- Low consumption;
- Our products are the CE certified, ROHS compliant, FCC identified;
- Your reply will be replied within 24 hours;
Product detail:
