Indoor LED Shelf Display COB 1.25mm Synchronous And Asynchronous Control
Indoor LED Shelf Display COB 1.25mm Synchronous And Asynchronous Control
Indoor LED Shelf Display COB 1.25mm Synchronous And Asynchronous Control
Indoor LED Shelf Display COB 1.25mm Synchronous And Asynchronous Control
Indoor LED Shelf Display COB 1.25mm Synchronous And Asynchronous Control
Indoor LED Shelf Display COB 1.25mm Synchronous And Asynchronous Control
Specifications
Model Number :
I-TAG COB 1.25
Brand Name :
longrun
MOQ :
1 Piece
Price :
Negotiable
Certification :
CE
Place of Origin :
ShenZhen,China
Payment Terms :
L/C, T/T
Packaging Details :
Carton/Plywooden case
Product name :
P1.25 COB Shelf Display
Application :
Super market,shop
Module size :
150*56.25mm
Power Supply :
5V 60A
LED chip :
COB
Cabinet size :
300mm*60mm
Brightness :
500cd/sqm
Certificate :
CE RoHS UL FCC Certifications
Usage :
Indoor
Description

Indoor LED Shelf Display COB 1.25mm Synchronous And Asynchronous Control

Technical Parameters

Item Parameters
Model P1.25
Pixel Pitch(mm) 1.25
Physical Density (dot/sqm) 640,000
LED Configuration 1RGB
Module Size (mmxmm) 150*56.25
Module Resolution (PXxPX) 120*45
Scanning mode 1/45
Brightness(cd/sqm) 500
Grey Scale 16bit
Refresh Rate(Hz) 2880Hz
Panel Resolution(PXxPX) 240*45
Panel Max Power Consumption(w) 15
Panel Average Power Consumption(w) 5
Panel Size(mmxmm) 300*56.25
Panel Weight(kg) 0.35
Panel Thickness(mm) 20
Panel Material Profile aluminum
Color(M) 16.7
Input Voltage AC110V-220V +/-10%

Our advantages:

1,2cm super slim thickness

2,modular design to match the standard supermaket shelf

3,optional panel size 300*56.25mm, 600mm*56.25mm or 900mm*56.25mm

4,easy assemble

5,support hot-plug

6,support hook type installation

7,quick delivery time 5-10 days

Product features:

1,Smaller pixel pitch: P1.25

2,Stronger protection: COB LED chips are welded on the PCB board directly, then do encapsulation. It has excellent protection capabilities.

3,Higher reliability and stability: COB technology has simpler process on material using and producing than SMD, so it has higher performance on heat dissipation to prolong life span.

4,Larger viewing angle: has larger viewing angle and is easy to control the loss of light refraction.

Detailed Images

Single panel reference: 600mm(W)*56.25mm(H)

Indoor LED Shelf Display COB 1.25mm Synchronous And Asynchronous Control

4 panel assembling reference: 2400mm(W)*56.25mm(H)

Indoor LED Shelf Display COB 1.25mm Synchronous And Asynchronous Control

Easy assembling with screws

Indoor LED Shelf Display COB 1.25mm Synchronous And Asynchronous Control

Support hot-plug

Indoor LED Shelf Display COB 1.25mm Synchronous And Asynchronous Control

Support hook type installation

Indoor LED Shelf Display COB 1.25mm Synchronous And Asynchronous Control

Indoor LED Shelf Display COB 1.25mm Synchronous And Asynchronous Control

Packaging & Shipping

Carton

Indoor LED Shelf Display COB 1.25mm Synchronous And Asynchronous Control

Certifications

Indoor LED Shelf Display COB 1.25mm Synchronous And Asynchronous Control

Advantages

Indoor LED Shelf Display COB 1.25mm Synchronous And Asynchronous Control
