60W Flat LED Street Lights For Outdoor Security 5 Years Warranty
60W Flat LED Street Lights For Outdoor Security 5 Years Warranty
60W Flat LED Street Lights For Outdoor Security 5 Years Warranty
60W Flat LED Street Lights For Outdoor Security 5 Years Warranty
60W Flat LED Street Lights For Outdoor Security 5 Years Warranty
60W Flat LED Street Lights For Outdoor Security 5 Years Warranty
60W Flat LED Street Lights For Outdoor Security 5 Years Warranty
60W Flat LED Street Lights For Outdoor Security 5 Years Warranty
60W Flat LED Street Lights For Outdoor Security 5 Years Warranty
60W Flat LED Street Lights For Outdoor Security 5 Years Warranty
Specifications
Brand Name :
DUALRAYS
Model Number :
DR-ST060-DG1
Certification :
CE,RoHS,LM79,LM80,TUV/GS,SAA,RCM,CB and D-Mark Available
Place of Origin :
Shenzhen,China
MOQ :
2pcs
Price :
negotiable
Delivery Time :
5-15 Bussiness Day
Packaging Details :
Netural Package/OEM and ODM Package Available
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
50000PCS/Month
Chips :
3030
Driver :
Meanwell
CRI :
>80Ra
Life Span :
50 000hrs
Input :
950-305VAC
Installation :
Wall Mounted
Description

60W Flat LED Street Lights For Outdoor Security 5 Years Warranty

60W Flat LED Street Lights For Outdoor Security 5 Years Warranty

60W Flat LED Street Lights For Outdoor Security 5 Years Warranty
> High brightness LUXEON SMD3030 LEDs,energy efficient - up to 150 lm/w;
> Die-casting Al for excellent heat dissipation;
> Superior PC reflector-optic for low glare applications,and toughened glass protection;
> IP66 and IK10 for road lighting application;
> Driver and housing separated by spacers;
> Professional 50(V)*120(H)°/75(V)*150°(H) optic for option;
> ±10°/-90°(<90W) or ±15°/-90°(>90W) lamp head adjustable;
> No UV or IR and completely mercury free;
> L80/B10 @ 50.000h;
> 5 years warranty,7 or 10 years warranty negotiated;
Options:
> Driver: ELG/HLG,Sosen;
> Controls and Dimming: 1-10V, DALI, PWM,Zigbee Wireless Dimming for option;
> 10KA SPD,20KA Meanwell SPD optional;
> 3-pins photocell controller ON/OFF,and 7-pins LORA/NEMA socket smart wireless control available;
> Zigbee module (Single-lamp Controller and centralized manager) with software for option;
> DALI driver and DALI Centralized Manager optional;
> Light pole adapter for different poles optional;
> Customized supported for special projects;
60W Flat LED Street Lights For Outdoor Security 5 Years Warranty
* Roadways.
* Avenues.
* Walkways.
* Loading Area.
* Parking lot.
* Playground.
* Sport and Stadium.

60W Flat LED Street Lights For Outdoor Security 5 Years Warranty
Model No. DR-ST060-DG1
Rated Power/W 60
Systen Efficiency/LPW 140
Color Temperature WW:3000±200K NW: 4000±200K DW:5000±200K CW: 5700±200K
Dimming Function 1-10VDC /DALI / PIR Sensor
Protections Short circuit/Over current/Over voltage/Over temperature
Anti-salty spray Grade A
Color Index >80Ra
Beam Angle Options Type I, Type II(Long&Medium), Type III(Medium), Type IV(Medium), Type V(Medium)
IP/Rating IP66
AC Input Volage/V AC100~277V 50/60Hz
Power Factor PF>0.95
Starting Time <0.1
LED Driver Meanwell
UGR <25
THD <10%
SDCM <5
Lumen Maintenance @ 6000 hrs >95%
Switching Cycle before Failure 100,000
Installation Diameter ø60,or adaptor
Surge Protection 6KV~10KV Buit in Driver/10KA 20KV/20KA 20KV
Material AL+PC
Life Span/hrs >50000
Warranty 5 years
Operation Temperature -40 ~ +55℃
Storage Temperature -40 ~ +85℃
Certificate CE ROHS D-MARK SAA
60W Flat LED Street Lights For Outdoor Security 5 Years Warranty
30W/60W Version
60W Flat LED Street Lights For Outdoor Security 5 Years Warranty
90W,120W/150W/180W Version
60W Flat LED Street Lights For Outdoor Security 5 Years Warranty

60W Flat LED Street Lights For Outdoor Security 5 Years Warranty
60W Flat LED Street Lights For Outdoor Security 5 Years Warranty

60W Flat LED Street Lights For Outdoor Security 5 Years Warranty
60W Flat LED Street Lights For Outdoor Security 5 Years Warranty
60W Flat LED Street Lights For Outdoor Security 5 Years Warranty60W Flat LED Street Lights For Outdoor Security 5 Years Warranty60W Flat LED Street Lights For Outdoor Security 5 Years Warranty60W Flat LED Street Lights For Outdoor Security 5 Years Warranty
60W Flat LED Street Lights For Outdoor Security 5 Years Warranty
Zigbee Wireless Intelligent Control Diagram
60W Flat LED Street Lights For Outdoor Security 5 Years Warranty
Zigbee Wireless Intelligent Control Operator Interface
60W Flat LED Street Lights For Outdoor Security 5 Years Warranty
60W Flat LED Street Lights For Outdoor Security 5 Years Warranty
DALI Device
60W Flat LED Street Lights For Outdoor Security 5 Years Warranty

DALI Intelligent Control Diagram
60W Flat LED Street Lights For Outdoor Security 5 Years Warranty 60W Flat LED Street Lights For Outdoor Security 5 Years Warranty

DALI Intelligent Control Operator Interface
60W Flat LED Street Lights For Outdoor Security 5 Years Warranty

60W Flat LED Street Lights For Outdoor Security 5 Years Warranty
Packaging Information
60W Flat LED Street Lights For Outdoor Security 5 Years Warranty

60W Flat LED Street Lights For Outdoor Security 5 Years Warranty

60W Flat LED Street Lights For Outdoor Security 5 Years Warranty

60W Flat LED Street Lights For Outdoor Security 5 Years Warranty

60W Flat LED Street Lights For Outdoor Security 5 Years Warranty

60W Flat LED Street Lights For Outdoor Security 5 Years Warranty

60W Flat LED Street Lights For Outdoor Security 5 Years Warranty

60W Flat LED Street Lights For Outdoor Security 5 Years Warranty

60W Flat LED Street Lights For Outdoor Security 5 Years Warranty

60W Flat LED Street Lights For Outdoor Security 5 Years Warranty 60W Flat LED Street Lights For Outdoor Security 5 Years Warranty

(DIALUX Simulation)
　　Dualrays adheres to independent innovation, Dualraysers try to build a world well-known LED industrial Lighting Brand.　　
60W Flat LED Street Lights For Outdoor Security 5 Years Warranty
(Partnership)
60W Flat LED Street Lights For Outdoor Security 5 Years Warranty
