60W LED Street Light Outdoor Security Lighting Type I Type II Type III Optics
60W LED Street Light Outdoor Security Lighting Type I Type II Type III Optics
60W LED Street Light Outdoor Security Lighting Type I Type II Type III Optics
60W LED Street Light Outdoor Security Lighting Type I Type II Type III Optics
60W LED Street Light Outdoor Security Lighting Type I Type II Type III Optics
60W LED Street Light Outdoor Security Lighting Type I Type II Type III Optics
60W LED Street Light Outdoor Security Lighting Type I Type II Type III Optics
60W LED Street Light Outdoor Security Lighting Type I Type II Type III Optics
60W LED Street Light Outdoor Security Lighting Type I Type II Type III Optics
60W LED Street Light Outdoor Security Lighting Type I Type II Type III Optics
Specifications
Brand Name :
DUALRAYS
Model Number :
DR-FL060-DG2
Certification :
CE,RoHS,LM79,LM80,TUV/GS,SAA,RCM,CB and D-Mark Available
Place of Origin :
Shenzhen,China
MOQ :
2pcs
Price :
negotiable
Delivery Time :
5-15 Bussiness Day
Packaging Details :
Netural Package/OEM and ODM Package Available
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
50000PCS/Month
Rated Wattage :
60W
Flux :
8400lm
Beam Angle :
Type II long/Medium
CCT :
3000-6500K
Life Span :
50000Hrs
Housing :
Die-Casting Al
Description

60W LED Street Light Outdoor Security Lighting Type I Type II Type III Optics

60W LED Street Light Outdoor Security Lighting Type I Type II Type III Optics

60W LED Street Light Outdoor Security Lighting Type I Type II Type III Optics
> Superior PC reflector-optic for low glare applications,and toughened glass protection;
> IP66 and IK10 for road lighting application;
> Driver and housing separated by spacers;
> Professional 50(V)*120(H)°/75(V)*150°(H) optic for option;
Options:
> Driver: ELG/HLG,Sosen;
> 3-pins photocell controller ON/OFF,and 7-pins LORA/NEMA socket smart wireless control available;
> Zigbee module (Single-lamp Controller and centralized manager) with software for option;
> DALI driver and DALI Centralized Manager optional;
60W LED Street Light Outdoor Security Lighting Type I Type II Type III Optics
* Roadways.
* Loading Area.
* Parking lot.
* Sport and Stadium.
60W LED Street Light Outdoor Security Lighting Type I Type II Type III Optics
Model No. DR-ST060-DGX
Rated Power/W 60
Protections Short circuit/Over current/Over voltage/Over temperature
Beam Angle Options Type I, Type II(Long&Medium), Type III(Medium), Type IV(Medium), Type V(Medium)
IP/Rating IP66
AC Input Volage/V AC100~277V 50/60Hz
Power Factor PF>0.95
THD <10%
SDCM <5
Lumen Maintenance 36000 hrs >90%
Installation Diameter ø60,or adaptor
Surge Protection 6KV~10KV Buit in Driver/10KA 20KV/20KA 20KV
Warranty 5 years
Storage Temperature -40 ~ +85℃
Certificate CE ROHS D-MARK SAA
60W LED Street Light Outdoor Security Lighting Type I Type II Type III Optics
30W/60W Version
60W LED Street Light Outdoor Security Lighting Type I Type II Type III Optics
90W,120W/150W/180W Version
60W LED Street Light Outdoor Security Lighting Type I Type II Type III Optics

60W LED Street Light Outdoor Security Lighting Type I Type II Type III Optics
60W LED Street Light Outdoor Security Lighting Type I Type II Type III Optics

60W LED Street Light Outdoor Security Lighting Type I Type II Type III Optics
60W LED Street Light Outdoor Security Lighting Type I Type II Type III Optics
60W LED Street Light Outdoor Security Lighting Type I Type II Type III Optics60W LED Street Light Outdoor Security Lighting Type I Type II Type III Optics60W LED Street Light Outdoor Security Lighting Type I Type II Type III Optics60W LED Street Light Outdoor Security Lighting Type I Type II Type III Optics
60W LED Street Light Outdoor Security Lighting Type I Type II Type III Optics
Zigbee Wireless Intelligent Control Diagram
60W LED Street Light Outdoor Security Lighting Type I Type II Type III Optics
Zigbee Wireless Intelligent Control Operator Interface
60W LED Street Light Outdoor Security Lighting Type I Type II Type III Optics
60W LED Street Light Outdoor Security Lighting Type I Type II Type III Optics
DALI Device
60W LED Street Light Outdoor Security Lighting Type I Type II Type III Optics

DALI Intelligent Control Diagram
60W LED Street Light Outdoor Security Lighting Type I Type II Type III Optics 60W LED Street Light Outdoor Security Lighting Type I Type II Type III Optics

DALI Intelligent Control Operator Interface
60W LED Street Light Outdoor Security Lighting Type I Type II Type III Optics

60W LED Street Light Outdoor Security Lighting Type I Type II Type III Optics
Packaging Information
60W LED Street Light Outdoor Security Lighting Type I Type II Type III Optics

60W LED Street Light Outdoor Security Lighting Type I Type II Type III Optics

60W LED Street Light Outdoor Security Lighting Type I Type II Type III Optics

60W LED Street Light Outdoor Security Lighting Type I Type II Type III Optics

60W LED Street Light Outdoor Security Lighting Type I Type II Type III Optics

60W LED Street Light Outdoor Security Lighting Type I Type II Type III Optics

60W LED Street Light Outdoor Security Lighting Type I Type II Type III Optics

60W LED Street Light Outdoor Security Lighting Type I Type II Type III Optics

60W LED Street Light Outdoor Security Lighting Type I Type II Type III Optics

60W LED Street Light Outdoor Security Lighting Type I Type II Type III Optics

In addition,we can provide our customers value added service with Dialux software for lighting design projects free of charge.
60W LED Street Light Outdoor Security Lighting Type I Type II Type III Optics 60W LED Street Light Outdoor Security Lighting Type I Type II Type III Optics

(DIALUX Simulation)
　　Dualrays adheres to independent innovation, Dualraysers try to build a world well-known LED industrial Lighting Brand.　　
60W LED Street Light Outdoor Security Lighting Type I Type II Type III Optics
(Partnership)
60W LED Street Light Outdoor Security Lighting Type I Type II Type III Optics
