Lightweight Transparent LED Screen Display Video Wall 500*1000mm TRA-M PH10-10
Lightweight Transparent LED Screen Display Video Wall 500*1000mm TRA-M PH10-10
Lightweight Transparent LED Screen Display Video Wall 500*1000mm TRA-M PH10-10
Lightweight Transparent LED Screen Display Video Wall 500*1000mm TRA-M PH10-10
Specifications
Place of Origin :
Guangdong, China
Model Number :
TRA-M PH10-10
Brand Name :
Highmight
Packaging Details :
Flight case/wooden case/carton case packing
Price :
$820/square meters >=1 square meters
Certification :
CE FCC RoHS
MOQ :
>=1 square meters
Payment Terms :
T/T
Delivery Time :
7-35 work days
Panel Size :
500mmX1000mm
Type :
LED
Material :
Die-casting Aluminum
Pixel Pitch :
10.4-10.4
Application :
Outdoor
Color :
full color
Media Available :
datasheet, Photo
Specification :
Video Wall
Brightness :
≥4500 cd/㎡
pixel density :
9216 dot/㎡
Lifespan (hours) :
≥100000H
IP Rating :
IP65
HS Code :
8528591090
Resolution :
96X96
Refresh rate :
3840HZ
Scan mode :
1/2 Scan
Feature :
Thin and Light
LED chip :
SMD2727
Description

500*1000mm TRA-M PH10-10 Outdoor lightweight design LED Transparent Display screen

Detailed product introduction document:Indoor transparent screen TRA-M series.pdf

Applicable scenarios :

1. stage performance

2. Commercial Plaza & Street

3. Tourism Rail/Fence

4. shopping mall and office building

5. exhibition hall

Features:

1. Transparent and invisible, see the shadow but not the screen

2. IP65 dustproof and waterproof

3. Clear picture without flicker and distortion.No light leakage trouble

4. high contrast and wide viewing angle

5. High refresh rate and gray scale ensures the picture quality remains seamless

(1) Building curtain wall:
LED transparent display will be attached to the glass keel installation, combined with the glass curtain wall, can achieve good advertising effect.
(2) Space design:
The LED transparent screen can be customized to different shapes to meet different space needs and achieve the effect of space beautification.

Product Details

Models:TRA-M PH10-10

Pixel Pitch (mm) 10.4-10.4 Conventional Power (W/㎡) 400-600W
Signal Connection WiFi / DVI / HDMI / DP / USB / RJ45 network cable / remote control system Control System Nova / Colorlight System / Magnimade System / Mooncell System
Pixel Density (dot/㎡) 9216 Transparency 60%
Cabinet Pixel 96X96 Protection Grade IP65
Refresh Rate (HZ) 3840Hz Eliminate Shadows Equipment
Driver Chip MY9866(same level) Input Voltage AC100～240V 50/60HZ
Scan Mode 1/2 Scan Module Input Voltage DC4.7～5V±0.2V
Lamp Type SMD2727 Cabinet Size (mm) 1000X500X80
Brightness (cd/㎡) ≥4500 Weight (kg/㎡) 12kg/㎡
Lifespan (hours) ≥100,000H Cabinet Material Die-casting Alumimum
Working Temperature and Humidity Temperature:-10～40℃ Humidity:10％-90％ Maintenance

power/Control System : rear maintenance

module:front maintenance
LED Composition RGB three in one Gray Scale 14bit
Maximum Power (W/㎡) 600-800W Installation hoisting/fixed installation/Build on standing structure

Applicable:

Lightweight Transparent LED Screen Display Video Wall 500*1000mm TRA-M PH10-10

Lightweight Transparent LED Screen Display Video Wall 500*1000mm TRA-M PH10-10

FQA:

Q1: How is the quality of the product?
A: Our products have been strictly tested before out of our factory. Strict quality management and control process are assured before shipping to customers.
