Specifications
Place of Origin :
Guangdong, China
Model Number :
TRA-B PH2-5
Brand Name :
Highmight
Packaging Details :
Flight case/wooden case/carton case packing
Price :
$430/square meters
Certification :
CE FCC RoHS
MOQ :
>=1 square meters
Payment Terms :
T/T
Delivery Time :
7-35 work days
Application :
Indoor
Panel Size :
1000mmX1000mm
Type :
LED
Color :
full color
Media Available :
datasheet, Photo
Pixel Pitch :
2.6-5.2
Specification :
Video Wall
Brightness :
≥800 cd/㎡
pixel density :
73728 dot/㎡
Lifespan (hours) :
≥100000H
IP Rating :
IP30
Resolution :
384X192
Usage :
Indoor Adverting Display
Installation :
Fixed Installation
Refresh rate :
1920Hz
LED chip :
SMD1515
Feature :
Thin and Bright
Scan mode :
1/12scan
Weight :
7.5kg/㎡
Material :
Aluminum Alloy
Description

Indoor waterproof TRA-B PH2-5 Transparent LED Screen Display Video Wall Fixed Installation

Detailed product introduction document:Indoor transparent screen TRA-B series.pdf

Applicable scenarios :

1. commercial real estate , stage performance

2. Culture and education
It can be used as a youth education base, and the school organizes activities to watch scenic spots, introduce culture and history, and enrich education methods.
3. Information release
It can publish a variety of information including text, images and videos, and has encryption and content review mechanisms to ensure the legal compliance of published content. The user-friendly program management function can automatically play content according to the pre-edited time and order.

4. play videos and pictures

5. exhibition hall , Retail Shop Glass Windows

6. stage performance

Features:

1. high permeability, high refresh and high gray scale

2. Arbitrary customization: can be customized into square, triangle, circle, cylinder (can be curved into arc) and other irregular shapes

3. good heat dissipation

4. Seamless large area splicing

5. super thin and light and Stunning image display

6. Support front and rear maintenance to reduce maintenance costs: the playback screen appears in a suspended style, which will not affect the building's lighting and vision.

7. High permeability, high light transmittance
8. Simple structure and light quality

9.LED transparent screen is easy to maintain
10. Save building lighting costs

Product Details

Models: TRA-B

Indoor transparent screen (TRA-B series)
models PH 2-5 PH 3-7 PH 5-10 PH 10-10 PH 15-15
Pixel Pitch (mm) 2.6 - 5.2 3.91 -7.82 5.2 -10.4 10.4-10.4 15.6-15.6
transparency 56% 76% 76% 76% 80%
Pixel Density (dot/㎡) 73728 32768 18432 9216 4096
Cabinet pixel 384X192 256X128 192X96 96X96 64X64
Refresh rate (Hz) 1920 1920 1920 1920 1920
Drive chip ICN2038S (same level) ICN2038S (same level) ICN2038S (same level) ICN2038S (same level) ICN2038S (same level)
Scan mode 1/12 Scan 1/16 Scan 1/4 Scan 1/4 Scan 1/2 Scan
LED lamp type SMD1515 SMD2121 SMD2121 SMD2727 SMD2727

Brightness

(cd/㎡)

≥800
Lifespan ≥ 100,000 hours
Pixel composition RGB three-in-one
Grey scale 14bit
Maximum power (W/㎡) 600-800W
Conventional power (W/㎡) 400-600W
LED control system Nova / Colorlight System / Magnimade System / Mooncell System
Signal connection WiFi / DVI / HDMI / DP / USB / RJ45 network cable / remote control system
Protection grade IP30
Eliminate Shadows equipment
input voltage AC100~240V 50/60HZ
Module input voltage DC4.7~5V±0.2V
Cabinet size (mm) 1000X1000X80
Weight (Kg/㎡) 7.5kg/㎡
Cabinet material Aluminium alloy
Maintenance Power/Control System : rear maintenance
Module:front maintenance
Working temperature and humidity Temperature: -10 ~ 40℃ and humidity: -10%-90% , without condensation.
Installation hoisting/fixed installation/Build on standing structure

Application:

Super Thin Transparent LED Screen Display Video Wall Fixed InstallationSuper Thin Transparent LED Screen Display Video Wall Fixed Installation

FQA:

Q1: How is the quality of the product?
A: Our products have been strictly tested before out of our factory. Strict quality management and control process are assured before shipping to customers.

Q2: How long could I get reply of my inquiry?
A:You will get a reply within 24 hours.

Q3: What can you buy from us?

A: Rental LED Display Screen / Transparent LED Screen Display / Outdoor LED Display Screen / LED Dance Floor Tiles / Small Pixel Pitch LED Screen / Indoor LED Display Screen / Creative LED Display / All In One LED Screen / Flexible LED Screen / LED Transparent Film Screen / Holographic LED Screen and Custom LED Screen.

Q4: How is the quality of the product?
A: Our products have been strictly tested before out of our factory. Strict quality management and control process are assured before shipping to customers.
