Aluminum Cabinet Outdoor LED Display Screen 480mm*320mm High-Definition Glasses-Free 3D Screen
Aluminum Cabinet Outdoor LED Display Screen 480mm*320mm High-Definition Glasses-Free 3D Screen
Aluminum Cabinet Outdoor LED Display Screen 480mm*320mm High-Definition Glasses-Free 3D Screen
Aluminum Cabinet Outdoor LED Display Screen 480mm*320mm High-Definition Glasses-Free 3D Screen
Aluminum Cabinet Outdoor LED Display Screen 480mm*320mm High-Definition Glasses-Free 3D Screen
Aluminum Cabinet Outdoor LED Display Screen 480mm*320mm High-Definition Glasses-Free 3D Screen
Specifications
Brand Name :
Highmight
Model Number :
FA-X
Certification :
CE FCC RoHS
Place of Origin :
Guangdong, China
MOQ :
>=1 square meters
Price :
$860.00/square meters >=1 square meters
Payment Terms :
T/T
Delivery Time :
7-35 work days
Packaging Details :
Flight case/wooden case/carton case packing
Type :
LED
Panel Size :
480mmx320mm
Color :
full color
Pixel Pitch :
4.44mm
Physical pixels (dot/㎡) :
50630
Brightness :
6000 cd/㎡
Lamp bead working life :
≥ 100,000 hours
Contrast Ratio :
≥5000:1
Refresh rate :
3840HZ
Module size :
Customizable
LED lamp bead model :
SMD1921
Scan method :
1/9
Grayscale :
14bit
Maximum power (W/㎡)resolution :
650W
Average power (W/㎡) :
200W
Description

FA-X 480mmx320mm Customized Outdoor waterproof and dustproof LED Display Screen

Detailed product introduction document:Outdoor fixed installation front maintenance FA-X ...

Applicable scenarios :
1. commercial real estate , stage performance
2. welcome display and restaurant
3. shopping mall glass curtain wall
4. Subway/Metro Station
5. Floor and Ceiling Display and Media Advertising
6. LED outdoor full-color display is widely used in the field of advertising. Whether it is a city street, a shopping mall, a stadium or a transportation hub, etc., LED outdoor full-color display can attract people's attention and convey advertising information and brand image.

Features:
1. high permeability, high refresh and high gray scale
2. We have experienced technology enginners team and sales team to answer and solve all your concerned matters.
3. ultra high brightness and High definition
4. Unique sealing and filling technology: sealing and filling technology not only protects the lamp beads, but also has a waterproof effect, and the waterproof level is as high as IP65.
5.All the raw materials of LED display are selected from famous brand high-quality products, and the most important LED lights are high-quality LED lights.

Product Details
Models: FA-X

Model number P4.44 P5.7 P6.66 P8 P10
Pixel pitch point (mm) 4.44 5.7 6.66 8 10
Module Size (mm) 480x320 480x320 480x320 480x320 480x320
Module pixel resolution 108x72 84x56 72x48 60x40 48x32
Physical pixels (dot/㎡) 50630 30625 22500 15625 10000
LED lamp bead model SMD1921 SMD2727 SMD2727 SMD2727 SMD2727
White Balance brightness (cd/㎡) 6000 6000 6000 6000 6000
Refresh rate (Hz) ≥3840 ≥3840 ≥3840 ≥3840 ≥3840
Scanning mode (constant current drive) 1/9 Sweep 1/7 sweep 1/6 sweep 1/4 sweep 1/2 sweep
PCB layers (mm) 4 4 2 2 2
Box size (mm) 960x960 960x960 960x960 960x960 960x960
Box pixel resolution 216x216 168x168 144x144 120x120 96x96
Box thickness (mm) 77 77 77 77 77
Lamp bead working life ≥ 100,000 hours
Contrast ≥5000:1
Viewing Angle 140°/140°
Temperature 2000-9500K
Gray level 14bit
Maximum power (W/㎡) 650W
Average power (W/㎡) 200W
deghosting equip
Input voltage

AC100～240V 50/60HZ (Wide voltage power supply)
AC200～240V 50/60HZ(narrow voltage power supply)
Module input voltage DC4.2～5V±0.2V
Class of protection Front IP65,backIP54
Operating temperature and humidity Temperature-10～50℃ Humidity10％-90％
Module + Weight (kg/ case) 28kg
Box material Die-cast aluminum
Maintenance mode Front and rear maintenance
Installation mode Fixed installation

Application:
Aluminum Cabinet Outdoor LED Display Screen 480mm*320mm High-Definition Glasses-Free 3D ScreenAluminum Cabinet Outdoor LED Display Screen 480mm*320mm High-Definition Glasses-Free 3D Screen

FQA:
Q1: How is the quality of the product?
A: Our products have been strictly tested before out of our factory. Strict quality management and control process are assured before shipping to customers.


Q2: How long could I get reply of my inquiry?
A:You will get a reply within 24 hours.


Q3: How is the quality of the product?
A: Our products have been strictly tested before out of our factory. Strict quality management and control process are assured before shipping to customers.
