Large Flexible LED Screen Display High Brightness Curved Video Wall Displays
Large Flexible LED Screen Display High Brightness Curved Video Wall Displays
Large Flexible LED Screen Display High Brightness Curved Video Wall Displays
Large Flexible LED Screen Display High Brightness Curved Video Wall Displays
Large Flexible LED Screen Display High Brightness Curved Video Wall Displays
Large Flexible LED Screen Display High Brightness Curved Video Wall Displays
Large Flexible LED Screen Display High Brightness Curved Video Wall Displays
Large Flexible LED Screen Display High Brightness Curved Video Wall Displays
Specifications
Brand Name :
Highmight
Model Number :
HMT-SA-P3
Certification :
CE FCC RoHS
Place of Origin :
Guangdong, China
MOQ :
>=1 square meters
Price :
$469/square meters
Payment Terms :
T/T
Delivery Time :
7-35 work days
Packaging Details :
Flight case/wooden case/carton case packing
Name :
Large Flexible LED Screen Display
Color :
Full Color
IP Grade :
IP65
Lifespan :
100,000 hours
Power Consumption :
400-600W
Brightness :
500-800 cd/㎡
Refresh Rate :
1920Hz
Screen Size :
Customized
Warranty :
2 years
Gray Scale :
14bit
Working Temperature :
-10～40℃
Module size :
320*160
Description

Indoor Outdoor SR-A energy efficient,high brightness high power conversion efficiency flexible led screen

Detailed product introduction document:PH1.25-PH2 Indoor Soft Module SR-A Series.pdf

Applicable scenarios:

1. commercial real estate

2. entertainment culture

3. stage performance

4. radio and television studios

5. commercial exhibition hall

Features:

1. We have experienced technology enginners team and sales team to answer and solve all your concerned matters.

2. High refresh rate and gray scale ensures the picture quality remains seamless.

3. Outdoor fixed installation, resistant to various working conditions

4. It delivers an image which is super subtle and without getting tired after a longtime watching

5. Super High Refresh Rate, High Frame Frequency, No Ghosting & Twisting or Smear

Product Details

Models: SR-A

LED Indoor Soft Module SR-A Series (PH1.25-PH2))
Module model (mm) SR-A 1.25 SR-A 1.5 SR-A 1.8 SR-A 2
Module point spacing (mm) 1.25 1.538 1.8605 2
Module Size (mm) 320x160 320x160 320x160 320x160
Module pixel 256x128 208x104 172x86 160x80
Density pixels (dot/㎡) 640000 422500 289444 250000
Lamp bead model SMD1010 SMD1212 SMD1515 SMD1515
Brightness (cd/㎡) ≤800 ≤800 ≤800 ≤800
Refresh rate (Hz) 3840 3840 3840 3840
Scanning mode 1/64sweep 1/52sweep 1/43sweep 1/40sweep
Module weight (kg) 16.5 16.5 16.5 16.5
Module thickness (mm) 10 10 10 10
Service life ≥100,000 hours
Pixel composition RGB 3-in-1
Grayscale 14bit
Maximum power (W/㎡) 1000-1200W
Average power (W/㎡) 400-600W
Eliminate ghosting Equipment
input voltage AC100～240V 50/60HZ
Module input voltage DC4.7～5V±0.2V
Environment Temperature -10～40℃ Humidity 10％-90％
Installation Magnetic suction/box installation

Application:

Large Flexible LED Screen Display High Brightness Curved Video Wall Displays

Large Flexible LED Screen Display High Brightness Curved Video Wall Displays

SQA:

Q: Does it consume a lot of power?
A: LED soft modules have a high energy efficiency design, low power consumption and low operating costs.
Q: What control methods are supported?
A: It supports multiple control methods, including computer remote control and smartphone applications.
Q: How is the color performance?
A: LED soft modules have rich colors, support high grayscale levels, and have excellent display effects.
Q: What is the price?
A: The price varies according to specifications, size and customization requirements. Please contact us for a quote.
