P 3.75-6.67 Transparent LED Screens For Advertising , Hd Transparent Led Panel
P 3.75-6.67 Transparent LED Screens For Advertising , Hd Transparent Led Panel
P 3.75-6.67 Transparent LED Screens For Advertising , Hd Transparent Led Panel
P 3.75-6.67 Transparent LED Screens For Advertising , Hd Transparent Led Panel
P 3.75-6.67 Transparent LED Screens For Advertising , Hd Transparent Led Panel
P 3.75-6.67 Transparent LED Screens For Advertising , Hd Transparent Led Panel
P 3.75-6.67 Transparent LED Screens For Advertising , Hd Transparent Led Panel
P 3.75-6.67 Transparent LED Screens For Advertising , Hd Transparent Led Panel
Specifications
Brand Name :
Bako Vision
Model Number :
BG
Certification :
CCC.CE.ETL.FCC
Place of Origin :
China
MOQ :
1 m²
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
8000 m²/month
Delivery Time :
20 days
Packaging Details :
Wooden Case
Panel Material :
Aluminum
Colours :
281 trillion
Greyscale :
16 bits
Contrast Ratio :
2000:1
Refresh Rate :
>1920 Hz
Servicing :
Rear
Description

P 3.75-6.67 Transparent LED Screens For Advertising , Hd Transparent Led Panel

Clean and See Glass

Excellent Viewing Angle

Hidden Cable Appearance

Easy to Install and Dismantle

Parameter

BG-3.75-6.66 BG-3.75-8 BG-5-6.66 BG-5-8
Physical Pitch 3.75 mm 3.75 mm 5 mm 5 mm
Pixel Configuration SMD SMD SMD SMD
Pixel Density

39,900 pixels/m²

33,250 pixels/m²

30,000 pixels/m²

40,000 pixels/m²
Module Dimensions (W × H) (mm) 480 × 320 480 × 320 480 × 320 480 × 320
Panel Dimensions (mm) 1920 × 640 1920 × 640 1920 × 640 1920 × 640
NO .of Modules Per Panel (W × H) 4 × 2 4 × 2 4 × 2 4 × 2
Physical Resolution of Module (W × H) 128 × 48 128 × 40 96 × 48 96 × 40
Physical Resolution of Panel (W × H) 512 × 96 512 × 80 384 × 96 384 × 80
Panel Material Aluminum Aluminum Aluminum Aluminum
Single Cabinet Weight 11 KG 10.2 KG 10 KG 9.5 KG
Processing 14 - 16 bit 14 - 16 bit 14 - 16 bit 14 - 16 bit
Colours 281 trillion 281 trillion 281 trillion 281 trillion
Contrast Ratio 2,000 : 1 2,000 : 1 2,000 : 1 2,000 : 1
Average Power Consumption 207 W/m² 201 W/m² 209 W/m² 203 W/m²
Max Power Consumption 690 W/m² 670 W/m² 696 W/m² 670 W/m²
Operating Temp/Humidity -10℃ - 60℃ / 10% - 60% -10℃ - 60℃ / 10% - 60% -10℃ - 60℃ / 10% - 60% -10℃ - 60℃ / 10% - 60%
Storage Temp/Humidity -30℃ - 60℃ / 10% - 60% -30℃ - 60℃ / 10% - 60% -30℃ - 60℃ / 10% - 60% -30℃ - 60℃ / 10% - 60%
Refresh Rate ＞1,920 Hz ＞1,920 Hz ＞1,920 Hz ＞1,920 Hz
Brightness 5,500 - 6,000nits 5,500 - 6,000nits 5,500 - 6,000nits 5,500 - 6,000nits
Horizontal Viewing Angle 140° 140° 140° 140°
Vertical Viewing angle 140° 140° 140° 140°
Expected Lifetime 100,000 Hrs 100,000 Hrs 100,000 Hrs 100,000 Hrs
IP Rating (Front/Rear) IP 30 IP 30 IP 30 IP 30
Servicing Rear Rear Rear Rear
Certification CCC, CE, ETL, FCC CCC, CE, ETL, FCC CCC, CE, ETL, FCC CCC, CE, ETL, FCC

Future

Slim, Light Weight and Quiet

35mm-45mm thickness

14kg per square meter

Available to attach onto glass wall directly

High Transparency and Concise

60-80% transparency rate among different pitches

Variable brightness options for day and night environment

Hidden cable design looks clean and concise

Special Emitting Angle

Lighting from tube side emitting

Brightness and color are penetrated via the glass effect

Embedded-In SMD Technology, avoid to be knocked off during transportation and installation

P 3.75-6.67 Transparent LED Screens For Advertising , Hd Transparent Led Panel

P 3.75-6.67 Transparent LED Screens For Advertising , Hd Transparent Led PanelP 3.75-6.67 Transparent LED Screens For Advertising , Hd Transparent Led Panel

COMPANY INTRODUCTION

Shenzhen BAKO VISION Technology Co.,Ltd, started in Shenzhen in 2005, a world class manufacturer of technologically advanced LED displays, is SHENZHEN BAKO LTD holding end professional customers among domestic and overseas markets.
Do not be hesitate to contact us if you have any quiry!

P 3.75-6.67 Transparent LED Screens For Advertising , Hd Transparent Led Panel

FAQ

Q1. Do you provide samples?is it free or extra?

A: We can supply the sample if we have ready parts in stock, but the customers have to pay the sample cost and the courier cost.

Q2.How to order?
A:Please send us your purchase order by Email or we can make you proforma invoice under your request.
We need to know the following information for your order before sending you PI.
1)Product information-Quantity,Specification(Size,Material,Technological if needed and Packing requirements etc.
2)Delivery time required.
3)Shipping information-Company name,Street address,Phone&Fax number,Destination sea port.
4)Forwarder's contact details if there's any in China.

Q3. Do you offer guarantee for the products?

A: Yes,we offer 2-5 years warranty to our products.
