110-240VAC Heliport Flood Light White Steady Burning IP66 Aluminum Alloy
110-240VAC Heliport Flood Light White Steady Burning IP66 Aluminum Alloy
110-240VAC Heliport Flood Light White Steady Burning IP66 Aluminum Alloy
110-240VAC Heliport Flood Light White Steady Burning IP66 Aluminum Alloy
Specifications
Brand Name :
Annhumg
Model Number :
AH-HP-CHAPI
Certification :
FAA
Place of Origin :
China
MOQ :
1
Price :
$149.00 - $179.00/ Piece
Payment Terms :
L/C, T/T, Western Union,
Supply Ability :
1000 Piece/Pieces per Month
Delivery Time :
3-15days
Packaging Details :
Plastic bag with paper carton.
Emitting Color :
White
Operation Mode :
24hours operation
Flash Characteristics :
Steady burning
Lamp Body Material :
Aluminum Alloy
Description
Product Description

Compliance

l ICAO Annex 14 Volume

l FAA AC 150/5390-2B Heliport Design Guide

Features

Electrical

l High intensity, energy efficient LED, glare-free floodlight

l Period of LED Life ≥100,000 hours

l Power supply available in AC(110-240VAC), DC48V, DC12V, etc

l Ultra-efficient LED reduce power consumption

Physical

l The enclosure is made out of stainless steel powder coated in electrostatic field, ensure it have good weather resistance

l The assembly has a low profile of less than 25cm and mounts to frangible point

l Specially custom lens optic designed specifically for helipad operation

l The angle of tilt of the luminaire is easily adjusted to maximise heliport illumination

Optional

l Infrared LED for pilot using NVG(Night Vision Goggles)

l Controller for power supplying and turn ON/OFF light

l VHF pilot to ground remote control

l Marine treated

Application

l Helipad/Heliport /Helideck

SPECIFICATIONS AH-HP-F1 LED Heliport Surface Flood Light
Light Characteristics
Light Source CREE Ultra high intensity LED
Emitting Color White
Luminous efficiency: 120lm/W 120lm/W
Flash Characteristics Steady burning
Operation Mode 24hours operation
LED Life Experience(hours) >100,000
Electrical Characteristics
Operating Voltage 110-240VAC, 48VDC, 24VDC or others
Power(W) 10
Physical Characteristics
Enclosure Material Powder Coated Stainless Steel
Overall size(mm) 230×230×165
Installation size(mm) 140×140×12
Weight(kg) 2.4
Product Life Expectancy

Average 5 years
Environmental Factors

Ambient Temperature(℃)

-55℃~+70℃

 -55~70
Humidity 0~100%
Wind Speed 80m/s
Waterproof IP66
Compliance
ICAO ICAO Annex 14 Volume
Options Available
Infrared LED compatible for NVG (Night
Vision Goggles)
Marine Treated

VHF pilot to ground remote control

Company information

Anhang Technology (HK) Company Limited is a high technology enterprise engaging in research, production, sales and after -sales services for a wide range of Aviation Obstruction Light,Aircraft Warning Light,Helipad Light, LED Marine Lanterns,LED Bulb and Aircraft Warning Sphere.We are a domestic market leader in the field of navigation lights and a supporter of green and safe emissions. Our products are widely used in Civil Airports, Helipads, Communication Towers, Factory,Power Plant Chimneys, Television Tower, Port, Bridges, and High-rise buildings, Buoyage in sea, etc.

All our products are designed and manufactured strictly according to ICAO (International Civil Aviation Organization), FAA (Federal Aviation Administration) and IALA(International Association of Lighthouse Authorities). We are proud to have served customers from all across the world.

Our Services

1. 2 years full warranty, 5 years maintenance since the purchasing date.

2.Since the purchasing date, full warranty from 1st year to 2nd year, free maintenance cost and material cost.

3.Since the purchasing date, maintenance from 3rd year to 5th year, free maintenance charge.
