3.0-inch 240*400 ST7796S IPS TFT LCD with SPI/MCU/RGB interfaces for industrial control and medical applications
3.0-inch 240*400 ST7796S IPS TFT LCD with SPI/MCU/RGB interfaces for industrial control and medical applications
3.0-inch 240*400 ST7796S IPS TFT LCD with SPI/MCU/RGB interfaces for industrial control and medical applications
3.0-inch 240*400 ST7796S IPS TFT LCD with SPI/MCU/RGB interfaces for industrial control and medical applications
3.0-inch 240*400 ST7796S IPS TFT LCD with SPI/MCU/RGB interfaces for industrial control and medical applications
3.0-inch 240*400 ST7796S IPS TFT LCD with SPI/MCU/RGB interfaces for industrial control and medical applications
Specifications
Place of Origin :
China
Payment Terms :
D/A, L/C, T/T
Brand Name :
WANSHUJIE
Price :
$1/pieces 1-99 pieces
Delivery Time :
1-2WEEKS
MOQ :
1pcs
Description

3.0-inch 240*400 ST7796S IPS TFT LCD with SPI/MCU/RGB interfaces for industrial control and medical applications

1. Module Name: 3.0-inch 240×400 ST7796S IPS TFT LCD with SPI/MCU/RGB Interface
2. Model:
3. Size: 3.0 inches
4. Resolution: 240×400
5. Similar Models:
6. Compatible Models:
7. Viewing Angle: Full viewing angle
8. Display Colors: 65K/262K
9. Display Mode: IPS TFT
10. Driver IC: ST7796S
11. Dot Pitch: 0.162*0.162 mm
12. Display Type: Transmissive, Normally Black
13. Outline Dimension: 45.04*77*2.6 mm
14. Viewable Area:
15. AA Area: 38.88*64.8 mm
16. Brightness: 400 cd/m²
17. Contrast Ratio: 600
18. Interface: SPI/MCU/RGB interface supported
19. Pin Count: 45PIN
20. Pin Pitch: 0.5mm
21. Connection Type: Plugging type
22. Operating Voltage: 3.3V
23. Backlight Color & Type: White LED backlight
24. Backlight Circuit: 4 LEDs in parallel, If=60-80mA, Vf=3.2V
25. Service Life: 50000h
26. Operating Temperature: -20-+70℃
27. Storage Temperature: -30-+80℃
28. Product Certification: ROHS
29. Quality System Certification: ISO9001 ISO13485 ISO14001 IATF16949

3.0-inch 240*400 ST7796S IPS TFT LCD with SPI/MCU/RGB interfaces for industrial control and medical applications

3.0-inch 240*400 ST7796S IPS TFT LCD with SPI/MCU/RGB interfaces for industrial control and medical applications3.0-inch 240*400 ST7796S IPS TFT LCD with SPI/MCU/RGB interfaces for industrial control and medical applications3.0-inch 240*400 ST7796S IPS TFT LCD with SPI/MCU/RGB interfaces for industrial control and medical applications

3.0-inch 240*400 ST7796S IPS TFT LCD with SPI/MCU/RGB interfaces for industrial control and medical applications3.0-inch 240*400 ST7796S IPS TFT LCD with SPI/MCU/RGB interfaces for industrial control and medical applications

3.0-inch 240*400 ST7796S IPS TFT LCD with SPI/MCU/RGB interfaces for industrial control and medical applications
