Specifications
Brand Name :
Zaozhuang NO.1
Model Number :
HMC1000
Certification :
CE,ISO
Place of Origin :
Shandong, China
MOQ :
1 set
Price :
115000USD
Payment Terms :
T/T
Supply Ability :
1000 sets/month
Delivery Time :
15 days after getting the deposit.
Packaging Details :
Export standard wooden case or as customers' requirement
Size of worktable (mm) :
1000x1000
X/Y/Z Axis stroke（mm） :
1600X1000X1000
pindle end taper/diameter（mm） :
BT50-190
Maximum load on table（kg） :
1500
X/Y/Z rail width（mm） :
55/55/65
Spindle motor power（kw） :
23
Form of Tool Magazine :
Disc／Chain
Description
Strong Rigidity CNC Milling Machine HMC1000 Horizontal Machining with BT50 Spindle Taper
Product Description:
The HMC1000 is a high-precision inverted T-type horizontal machining center designed for efficient and reliable parts processing. Boasting a horizontal structure and transverse table movement, it delivers outstanding operational stability. Its robust cast iron bed provides excellent rigidity, making it capable of handling large and heavy workpieces. Equipped with a high-speed spindle and automatic tool changer, the machine significantly enhances machining efficiency. With multi-axis control and a 360° rotary table, it effortlessly performs complex multi-sided machining tasks.
Standard Configuration:

1.Syntec 22ma control system
2.Bt50 Taiwan 8000 RPM spindle
3.Taiwan hiwin screw
4.Taiwan hiwin 3 axis roller linear rails
5.Taiwan OKADA 30 -Disc- atc
6.Table: 700 x 630 mm 1 °/360 °
Product Specification:
Item Model
Unit
HMC1000
Size of worktable
mm
1000*1000
Table graduation
mm
1°*360
Maximum load on table
kg
1500
Number of worktables

1
X/Y/Z rail width
mm
55/55/65
X/Y/Z screw diameter
mm
6312/5012/6312
X/Y/Z Axis stroke
mm
1600*1000*1000
X/Y/Z motor torque
mm
28/30/30
Distance from spindle face to table
mm
200-1200
Distance from spindle center to column
mm
120-1120
Cutting feed rate
mm/min
10000
X/Y/Z axis fast feed
mm/min
20/20/20
Spindle en taper
mm
BT50-190
Spindle motor power
kw
23
Maximum spindle speed
rpm
6000
Form of Tool Magazine
-
Disc/Chain type
Maximum tool diameter/weight
mm/kg
118/200-25
Tool change time
sec
2.5
Positioning accuracy
mm
0.008
Repeat positioning accuracy
mm
0.005
The smallest unit of positioning
mm
0.001
Weight of machine tool
kg
14500
External dimensions
mm
5500*4500*3500

Details Display:
Strong Rigidity CNC Milling Machine HMC1000 Horizontal Machining with BT50 Spindle Taper
Strong Rigidity CNC Milling Machine HMC1000 Horizontal Machining with BT50 Spindle Taper
Strong Rigidity CNC Milling Machine HMC1000 Horizontal Machining with BT50 Spindle Taper
Strong Rigidity CNC Milling Machine HMC1000 Horizontal Machining with BT50 Spindle Taper
