808nm 10W C Mount Mini Laser Diode FAC Optional
808nm 10W C Mount Mini Laser Diode FAC Optional
808nm 10W C Mount Mini Laser Diode FAC Optional
808nm 10W C Mount Mini Laser Diode FAC Optional
808nm 10W C Mount Mini Laser Diode FAC Optional
808nm 10W C Mount Mini Laser Diode FAC Optional
Specifications
Brand Name :
Xinland
Model Number :
XLD-808-010-C
Certification :
N/A
Place of Origin :
China
MOQ :
10 Units
Price :
Negotiated
Payment Terms :
Western Union, MoneyGram, T/T, L/C
Supply Ability :
5000 units each Month
Packaging Details :
100pcs per carton
Center Wavelength :
808nm
Spectral Width :
3.5nm
Power :
5W
Package :
C-MOUNT
Emitter Area :
400x1μm
Beam Divergence :
33°┴ x 12°//
Description

808nm 10W High Power C-mount Package Mini Laser Diode FAC Optional

Features:

808nm
CW
C-MOUNT

Application:

Medical Laser Equipment
Laser Indicator
Laser Detector

C-mount package


Technical Datasheet:

Reverse Voltage

Vr

2.0

 V

Operating Temperature

Top

+10~+30

°C

Storage Temperature

Tstg

-20 ~ +80

°C

Lead soldering temperature (10 sec.)

Tis

260

°C


Laser Specification :

Min Type Max
Center Wavelength@25°C +/-5nm 808nm +/-10nm
Spectral Width (FWHM) -- 3.5nm --
Output Power -- 10W --
Emitter Area -- 400x1μm --
Beam Divergence (FWHM) -- 33°┴ x 12°// --
Temperature Coefficient of Wavelength -- 0.3nm / °C --
Slope Efficiency -- 1.1W/A --
Threshold Current (Typ.) -- 1.5A --
Operating Current (Typ.) 12A --
Operating Voltage ---

2.2 V

 -


C-mount Drawing :

808nm 10W C Mount Mini Laser Diode FAC Optional
