Multifunctional 1500 Watt Laser Welder
Multifunctional 1500 Watt Laser Welder
Multifunctional 1500 Watt Laser Welder
Multifunctional 1500 Watt Laser Welder
Multifunctional 1500 Watt Laser Welder
Multifunctional 1500 Watt Laser Welder
Multifunctional 1500 Watt Laser Welder
Multifunctional 1500 Watt Laser Welder
Multifunctional 1500 Watt Laser Welder
Multifunctional 1500 Watt Laser Welder
Multifunctional 1500 Watt Laser Welder
Multifunctional 1500 Watt Laser Welder
Specifications
Place of Origin :
Shenzhen
Brand Name :
DAPENG
Packaging Details :
Plywood box
Supply Ability :
300 sets per month
Price :
USD1000-5500
Model Number :
DPH-1500
Certification :
CE, ISO
MOQ :
1 set
Payment Terms :
T/T
Delivery Time :
5-10 days
Condition :
New
Max. Output Power :
1000W-3000W
Usage :
metal welding
Wavelength :
1064nm
Warranty :
1 Year
Control System Brand :
Depeng
Weight (KG) :
230 KG
Key Selling Points :
Easy to Operate
Applicable Industries :
Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Construction works , Energy & Mining, Advertising Company, Other
Machinery Test Report :
Provided
Video outgoing-inspection :
Provided
Marketing Type :
Ordinary Product
Warranty of core components :
1.5 years
Product name :
Laser Welding Cutting Cleaning Machine
Function :
Metal Part Laser Welding
Application material :
Aluminum Stainless Steel Carbon Steel
Cutting Materials :
Steel Iron Aluminum Carbon Steel
Welding head :
Double Wobble Handheld Welding Head
Power Consumption :
1000W/1500W/2000W/3000W
Cooling method :
Water Chiller Hanli
Applied industry :
Rust Remove Metal Cleaning
Laser source :
IPG Raycus Max JPT
Keywords :
3 in 1 Fiber Laser Welding Equipment
Port :
China or Shen zhen Ports
Description
Product Description
1000W 1500W 2000W Laser Welding Machine Soldering Machine Handheld Wobble Head Laser Welder with Auto Wire Feeder
Multifunctional 1500 Watt Laser Welder
Specification
Model
DPH-1000
DPH-1500
DPH-2000
Laser source type
Fiber source
Fiber source
Fiber source
Function
3 IN 1 Handheld Fiber Laser Cleaning Welding Cutting Machine
Laser Out Power
1000W
1500W
2000W
Laser wavelength
1070nm
1070nm
1070nm
Laser Source
Raycus/Max/IPG/nLIGHT
Raycus/Max/IPG/nLIGHT
Raycus/Max/IPG/nLIGHT
Focal spot diameter
0.1-3mm
0.1-3mm
0.1-3mm
Laser frequency
1-50Hz
1-50Hz
1-50Hz
Repeatability
±0.01mm
±0.01mm
±0.01mm
Machine operating temperature
0~40℃
0~40℃
0~40℃
Electricity demand
220V
220V
220V/380V
Cooling method
Water Chiller Hanli
Water Chiller Hanli
Water Chiller Hanli
Continuous operating time
24 hours
24 hours
24 hours
Weight
230kg
230kg
230kg
Dimensions
100*100*172cm
100*100*172cm
100*100*172cm
Laser control system
Depeng Touch screen
Depeng Touch screen
Depeng Touch screen
Features:
Handheld Fiber Laser Cleaning&Welding&Cutting Machine Description
The laser cleaning and welding machine can not only clean the metal surface contaminants, but also weld and combine various metal materials.
It is a mlti-functinal laser equipment. Equipped with Ruida system, it has two modes of cleaning and welding, which can be flexibly switched.
1. Fast and concentrated pulses with enormous power impact and gasification of residues on the surface;
2. Laser pulses are verysuitable for the removal of organic matter, such as residues in the tire mold fouling;
3. The impact of a short period of timewill not cause metal surface heating, no damage to the substrate.
4. Clean or remove the surface paint layer quickly and cleanly;
5. Accurate cleaning and paint removal effect;
6. No damage to the base material.
Cleaning
Fiber laser cleaning head has a good cleaning effect on iron, carbon steel plate, stainless steel plate, mold steel gear, aluminum plate, paint layer and other materials. The laser cleaning mode can clean the oxide layer, remove the paint on the surface, clean the surface oil, stains and dit, clean the rubber mold residue.
Meet the requirements for equipment cleaning in the shipbuilding industry, auto parts, rubber molds, machine tools, environmental protection industries and other fields.
Welding
Fiber laser welding head is suitable for stainless steel, copper, aluminum, gold, chromium, nickel and other metals or alloys It can also be used for a varies of welding between different material, such as copper - brass, titanium gold, nickel - copper and so on. Meet the welding needs of kitchen cabinets, stair elevators, shelves, ovens, stainless steel door and window guardrails, craft gifts, home furnishing and other industries.
Industry application
The hand-held laser welding machine can be widely used in complex and irregular welding processes in cabinet, kitchen and toilet supplies, stairs, elevators, shelves, ovens, stainless steel doors, and windows, guardrails, electric cabinet, stainless steel furniture and other industries.
Multifunctional 1500 Watt Laser Welder
Multifunctional 1500 Watt Laser Welder
Multifunctional 1500 Watt Laser Welder
Multifunctional 1500 Watt Laser Welder
Multifunctional 1500 Watt Laser Welder
Multifunctional 1500 Watt Laser Welder
Multifunctional 1500 Watt Laser Welder
Multifunctional 1500 Watt Laser Welder
Multifunctional 1500 Watt Laser Welder
Multifunctional 1500 Watt Laser Welder
Multifunctional 1500 Watt Laser Welder
Multifunctional 1500 Watt Laser Welder
Multifunctional 1500 Watt Laser Welder
Company Profile
Shenzhen Dapeng Laser Technology Co, Ltd. was established in 2011. It is a laser equipment high-tech enterprise that integrates R&D, manufacturing, sales and service. It is dedicated to laser process R&D, laser equipment design R&D, production, technical support, service and consulting. Our company's main products include: laser cutting machine, laser welding machine, laser marking machine, industry-specific and automated laser equipment, etc, applied to electronics, IC chips, electrical appliances, lighting fixtures, jewelry, hardware tools, sanitary ware, instruments Instrumentation, automobile and motorcycle accessories, mobile phone communications components, molds, precision machinery, medical equipment, IT digital, metal housing, military aviation components, garment leather, craft gifts, advertising decoration, models, cookware, kitchen utensils and other industries. Dapeng laser product quality are stable and reliable, with a professional R & D team, while pursuing excellent quality, Dapeng laser also provides customers with timely, comfortable pre-sale, sales, after-sales service and excellent cost-effective products. Dapeng Laser has won the trust and praise of customers by implementing the business philosophy of "helping customers succeed, creating value models, and building industrial laser equipment industry to serve high-end brands". Customers are located throughout the country and overseas. In 2016, sold more than 5,000 laser equipment. Our company has established a complete production and sales and after-sales service system, has production bases in Shenzhen, Wenzhou,Kunshan and Xiamen, has a large-scale laser cutting machine production base in Dongguan, and has offices in major domestic industrial cities and regions. There are equipment demonstrations, process proofing, sales and after-sales services, and resident technical service personnel, to provide customers with timely, comfortable pre-sales, sales, after-sales support and services.
Multifunctional 1500 Watt Laser Welder
Multifunctional 1500 Watt Laser Welder
Multifunctional 1500 Watt Laser Welder
Our Workshop
Multifunctional 1500 Watt Laser Welder
Multifunctional 1500 Watt Laser Welder
Why Choose US
Dapeng Laser has established a complete production and sales and after-sales service system, has production bases in Shenzhen, Wenzhou,Kunshan and Xiamen, has a large-scale laser cutting machine production base in Dongguan, and has offices in major domestic industrial cities and regions. There are equipment demonstrations, process proofing, sales and after-sales services, and resident technical service personnel, to provide customers with timely, comfortable pre-sales, sales, after-sales support and services. Dapeng people know that quality and service are fundamental to the survival of the company. Innovation is the foundation for the long-tem development of the company. It helps customers create value and strives to build a well-known brand in the laser equipment industry.
Multifunctional 1500 Watt Laser Welder
Multifunctional 1500 Watt Laser Welder
Laser Welding Machine Team
Multifunctional 1500 Watt Laser Welder
Laser Cutting Machine Team
Multifunctional 1500 Watt Laser Welder
Oversea Marketing Team
Our Exhibition
Multifunctional 1500 Watt Laser Welder
Multifunctional 1500 Watt Laser Welder
Multifunctional 1500 Watt Laser Welder
Multifunctional 1500 Watt Laser Welder
Our Certificates
Multifunctional 1500 Watt Laser Welder
CE
Multifunctional 1500 Watt Laser Welder
ISO
Multifunctional 1500 Watt Laser Welder
Multifunctional 1500 Watt Laser Welder
Multifunctional 1500 Watt Laser Welder
Multifunctional 1500 Watt Laser Welder
Packing & Delivery
We support to ship via Sea, Railway,Air, Express(UPS, DHL, EMS, Swiss Post, HongKong Post, FedEx, TNT). You also can choose the shipping method you like if you prefer another courier.
Multifunctional 1500 Watt Laser Welder
FAQ:
Q1: How do I know which model is suitable for my product application?
You just need to tell us the following information then we can offer you a suitable solution? In addition, you can also send us the sample and we will arrange professional engineers for proofing evaluation
1) What is your product? material? thickness? required accuracy?
2) What is the current production process?
3) What is your desired budget and delivery time.
Q2: When I get this machine, but I don't know how to use it. What should I do?
We will send teaching video of both installation and operation, as well as the English manual. If you have further questions, we have engineers who can speak English can serve you on-line directly. And for some countries , like in India, Malaysia, Korea,Spain, we have local support team, more countries will be in the picture soon.
Q3: How can I do if the machine goes wrong?
We guarantee machine quality for 13 months, during this period, if spare parts of the machine were not man-made damaged, we can send the component to the customer in best delivery. Besides guarantee period, we still provide you free online services for life.If parts broken, you can order replacement parts from us.
Q4. Can you customized product according to different application?
Yes, Dapeng laser is very dedicated to combine with our current ability with the main leading supplier to offer you the customized application.
Q5:What if there are gaps in my product which need to weld?
For laser welding machines, we are usually equipped with automatic wire feeding system. For products with gaps, you can use wire feeding mechanism for wire filling welding
Q6. What is your normal lead time?
Generally standard machine, our lead time is 2-7 days after PO confirmed. Customized product need a little longer.
Q7. Will the package damaged during transportation?
Our package is considerate all the damage factors and make it to be safe, and our shipping agent have full experienced in safe tranportation. We have exported to 80 countries worldwide. So please don't worry, you will receive the parcel in good condition
Q8:Why should I choose DAPENG LASER compared with other companys?
We are factory with 453 employees, turnover reached 100 millions USD in 2021, ISO 9001 certificated and most products are CE/SGS approoved, can offer you a high-quality pre-sale, in-sale and after-sales solution.
