Durable Steel Fiber Laser CNC Cutting Machine Automatic Multiscene
Durable Steel Fiber Laser CNC Cutting Machine Automatic Multiscene
Durable Steel Fiber Laser CNC Cutting Machine Automatic Multiscene
Durable Steel Fiber Laser CNC Cutting Machine Automatic Multiscene
Durable Steel Fiber Laser CNC Cutting Machine Automatic Multiscene
Durable Steel Fiber Laser CNC Cutting Machine Automatic Multiscene
Durable Steel Fiber Laser CNC Cutting Machine Automatic Multiscene
Durable Steel Fiber Laser CNC Cutting Machine Automatic Multiscene
Durable Steel Fiber Laser CNC Cutting Machine Automatic Multiscene
Durable Steel Fiber Laser CNC Cutting Machine Automatic Multiscene
Specifications
Place of Origin :
Guangdong, China
Brand Name :
DAPENG
Packaging Details :
Plywood box
Supply Ability :
50 sets per month
Price :
USD1000-45000
Model Number :
DPE-F6000
Certification :
CE, ISO
MOQ :
1 set
Payment Terms :
T/T
Delivery Time :
30 days
Application :
LASER CUTTING
Condition :
New
Laser Type :
Fiber Laser
Cutting Area :
1500mm*3000mm
Cutting Speed :
120m/min
Graphic Format Supported :
AI, PLT, DXF, BMP, Dst, Dwg, LAS, DXP
CNC or Not :
Yes
Cooling Mode :
WATER COOLING
Control Software :
Cypcut
Laser Source Brand :
RAYCUS / IPG / nLIGHT / MAX (Optional)
Laser Head Brand :
WSX
Servo Motor Brand :
YASKAWA / SCHNEIDER / MOTOR POWER(Optional)
Guiderail Brand :
HIWIN
Control System Brand :
Cypcut
Weight (KG) :
5600 KG
Key Selling Points :
Automatic
Warranty :
1 Year
Machinery Test Report :
Provided
Video outgoing-inspection :
Provided
Core Components :
Pressure vessel, Motor, Bearing, Gear, Pump, Gearbox, Engine, PLC, Other
Mode of Operation :
continuous wave
Products handled :
Sheet Metal
Product name :
Exchange Platform Fiber Laser Cutter
Laser source type :
Fiber source
Cutting materials :
Stainless Steel Carbon Steel
Laser output power :
1500W/2000W/3000W/6000W
Cutting range :
3000*1500mm
Cooling method :
Water cooling
Transfer method :
Precision rack dual drive
Keywords :
CNC Laser Cutting Machine
Port :
China or Shen zhen Ports
Description
Product Description
Dapeng Automatic Feed Exchange Platform 1500W 2000W 3000W 6000W Metal Stainless Steel Fiber CNC Laser Cutter Machine
Durable Steel Fiber Laser CNC Cutting Machine Automatic Multiscene
Specification
Model
DPE-FT3015D-F1500W/F2000W/F3000W
Laser source type
Fiber source
Laser Out Power
1070nm
Laser wavelength
1000W/2000W/3000W/6000W
Cutting range
3000×1500mm
Minimum line width
<0.1mm
Transfer method
Precision rack dual drive
Cutting speed and thickness
Depending on specific material
Repeatability
±0.02mm
Machine operating temperature
0~40℃
Electricity demand
380V/50Hz
Cooling method
Water cooling
Continuous operating time
24 hours
Weight
5600KG
Dimensions
8350x3050x2100mm
Maximum operating speed
120m/min
Maximum acceleration
0.9G
X/Ypositioning accuracy
1.2mm
Minimum slit width
0.15mm
Features:
Product Features
1,Gantry double drive structure, smooth and reliable movement.
2,Thickened heavy machine bed and worktable, no deformation for 20 years, greatly extending the service life of the machine.
3,Precision gear rack drive, with high response and high precision servo motor.
4,The international first-class quality of fiber laser, industrial application for many years, long service life, maintenance free, stable and reliable.
5,High precision laser cutting head, imported optical lenses, is focused on the fine, the adjustment is convenient, cutting perfect.
6,A double closed-loop control capacitive height controller, low requirement to the steel sheet, cutting quality is stable and reliable.
7,CNC system is concise and easy operation, low requirements for the operator.
8,Cutting graphic input multiple formats, powerful draw and edit graphics function.
9,China top professional laser cutting software, cutting technology experts, data call functions.

Advantages
* Using Germany IPG laser source, the electro-optical conversion efficiency is high, which can save power consumption during work and save operating cost.
* The design of the dual platform, when one workbench is cutting, the other workbench can simultaneously work on the loading and unloading to improve work efficiency.
* The focal length of the cutting head can be self-adjusted following the surface height of the material, even if the surface of the material is not flat, the cutting quality can be guaranteed.
* Equipped with a handheld controller, you can manually control the cutting position
* With precision ball screw, rack and pinion, linear guide transmission operation, thus achieving high precision, high efficiency and stability of the machine tool.
* The switch of the solenoid valve and the proportional valve is controlled by the system. The input value in the numerical control system can control the size of the proportional valve outlet, without manual adjustment.
* High-strength integrated welding fuselage and aerospace-grade aluminum alloy beams are subjected to high-temperature annealing to ensure long-term use without deformation.

Applications
1. Application Industries: Widely used in manufacturing Billboard, Advertising, Signs, Signage, Metal Letters, LED Letters, Kitchen Ware, Advertising Letters, Sheet Metal Processing, Metals Components and Parts, Ironware, Racks & Cabinets Processing, Metal Crafts, Metal Art Ware, Elevator Panel Cutting, Hardware, Auto Parts, Glasses Frame, Electronic Parts, Nameplates, etc.
2. Application Materials: Suitable for metal cutting with Stainless Steel Sheet, Steel Plate, Carbon Steel Sheet, Alloy Steel Plate, Iron Plate, Galvanized Sheet, Aluminum Plate, Copper Sheet, Brass Sheet, Bronze Plate, Gold Plate, Silver Plate, Metal Sheet,Metal Plate, Tubes and Pipes, etc.
Durable Steel Fiber Laser CNC Cutting Machine Automatic Multiscene
Durable Steel Fiber Laser CNC Cutting Machine Automatic Multiscene
Durable Steel Fiber Laser CNC Cutting Machine Automatic Multiscene
Durable Steel Fiber Laser CNC Cutting Machine Automatic Multiscene
Durable Steel Fiber Laser CNC Cutting Machine Automatic Multiscene
Durable Steel Fiber Laser CNC Cutting Machine Automatic Multiscene
Company Profile
Shenzhen Dapeng Laser Technology Co, Ltd. was established in 2011. It is a laser equipment high-tech enterprise that integrates R&D, manufacturing, sales and service. It is dedicated to laser process R&D, laser equipment design R&D, production, technical support, service and consulting. Our company's main products include: laser cutting machine, laser welding machine, laser marking machine, industry-specific and automated laser equipment, etc, applied to electronics, IC chips, electrical appliances, lighting fixtures, jewelry, hardware tools, sanitary ware, instruments Instrumentation, automobile and motorcycle accessories, mobile phone communications components, molds, precision machinery, medical equipment, IT digital, metal housing, military aviation components, garment leather, craft gifts, advertising decoration, models, cookware, kitchen utensils and other industries. Dapeng laser product quality are stable and reliable, with a professional R & D team, while pursuing excellent quality, Dapeng laser also provides customers with timely, comfortable pre-sale, sales, after-sales service and excellent cost-effective products. Dapeng Laser has won the trust and praise of customers by implementing the business philosophy of "helping customers succeed, creating value models, and building industrial laser equipment industry to serve high-end brands". Customers are located throughout the country and overseas. In 2016, sold more than 5,000 laser equipment. Our company has established a complete production and sales and after-sales service system, has production bases in Shenzhen, Wenzhou,Kunshan and Xiamen, has a large-scale laser cutting machine production base in Dongguan, and has offices in major domestic industrial cities and regions. There are equipment demonstrations, process proofing, sales and after-sales services, and resident technical service personnel, to provide customers with timely, comfortable pre-sales, sales, after-sales support and services.
Durable Steel Fiber Laser CNC Cutting Machine Automatic Multiscene
Durable Steel Fiber Laser CNC Cutting Machine Automatic Multiscene
Durable Steel Fiber Laser CNC Cutting Machine Automatic Multiscene
Our Workshop
Durable Steel Fiber Laser CNC Cutting Machine Automatic Multiscene
Durable Steel Fiber Laser CNC Cutting Machine Automatic Multiscene
Why Choose US
Dapeng Laser has established a complete production and sales and after-sales service system, has production bases in Shenzhen, Wenzhou,Kunshan and Xiamen, has a large-scale laser cutting machine production base in Dongguan, and has offices in major domestic industrial cities and regions. There are equipment demonstrations, process proofing, sales and after-sales services, and resident technical service personnel, to provide customers with timely, comfortable pre-sales, sales, after-sales support and services. Dapeng people know that quality and service are fundamental to the survival of the company. Innovation is the foundation for the long-tem development of the company. It helps customers create value and strives to build a well-known brand in the laser equipment industry.
Durable Steel Fiber Laser CNC Cutting Machine Automatic Multiscene
Durable Steel Fiber Laser CNC Cutting Machine Automatic Multiscene
Laser Welding Machine Team
Durable Steel Fiber Laser CNC Cutting Machine Automatic Multiscene
Laser Cutting Machine Team
Durable Steel Fiber Laser CNC Cutting Machine Automatic Multiscene
Oversea Marketing Team
Our Exhibition
Durable Steel Fiber Laser CNC Cutting Machine Automatic Multiscene
Durable Steel Fiber Laser CNC Cutting Machine Automatic Multiscene
Durable Steel Fiber Laser CNC Cutting Machine Automatic Multiscene
Durable Steel Fiber Laser CNC Cutting Machine Automatic Multiscene
Our Certificates
Durable Steel Fiber Laser CNC Cutting Machine Automatic Multiscene
CE
Durable Steel Fiber Laser CNC Cutting Machine Automatic Multiscene
ISO
Durable Steel Fiber Laser CNC Cutting Machine Automatic Multiscene
Durable Steel Fiber Laser CNC Cutting Machine Automatic Multiscene
Durable Steel Fiber Laser CNC Cutting Machine Automatic Multiscene
Durable Steel Fiber Laser CNC Cutting Machine Automatic Multiscene
Packing & Delivery
We support to ship via Sea, Railway,Air, Express(UPS, DHL, EMS, Swiss Post, HongKong Post, FedEx, TNT). You also can choose the shipping method you like if you prefer another courier.
Durable Steel Fiber Laser CNC Cutting Machine Automatic Multiscene
FAQ:
Q1: How do I know which model is suitable for my product application?
You just need to tell us the following information then we can offer you a suitable solution? In addition, you can also send us the sample and we will arrange professional engineers for proofing evaluation
1) What is your product? material? thickness? required accuracy?
2) What is the current production process?
3) What is your desired budget and delivery time.
Q2: When I get this machine, but I don't know how to use it. What should I do?
We will send teaching video of both installation and operation, as well as the English manual. If you have further questions, we have engineers who can speak English can serve you on-line directly. And for some countries , like in India, Malaysia, Korea,Spain, we have local support team, more countries will be in the picture soon.
Q3: How can I do if the machine goes wrong?
We guarantee machine quality for 13 months, during this period, if spare parts of the machine were not man-made damaged, we can send the component to the customer in best delivery. Besides guarantee period, we still provide you free online services for life.If parts broken, you can order replacement parts from us.
Q4. Can you customized product according to different application?
Yes, Dapeng laser is very dedicated to combine with our current ability with the main leading supplier to offer you the customized application.
Q5:What if there are gaps in my product which need to weld?
For laser welding machines, we are usually equipped with automatic wire feeding system. For products with gaps, you can use wire feeding mechanism for wire filling welding
Q6. What is your normal lead time?
Generally standard machine, our lead time is 2-7 days after PO confirmed. Customized product need a little longer.
Q7. Will the package damaged during transportation?
Our package is considerate all the damage factors and make it to be safe, and our shipping agent have full experienced in safe tranportation. We have exported to 80 countries worldwide. So please don't worry, you will receive the parcel in good condition
Q8:Why should I choose DAPENG LASER compared with other companys?
We are factory with 453 employees, turnover reached 100 millions USD in 2021, ISO 9001 certificated and most products are CE/SGS approoved, can offer you a high-quality pre-sale, in-sale and after-sales solution.
