Digital Portable Interactive Whiteboard Finger Touch Magnetic Board
Digital Portable Interactive Whiteboard Finger Touch Magnetic Board
Digital Portable Interactive Whiteboard Finger Touch Magnetic Board
Digital Portable Interactive Whiteboard Finger Touch Magnetic Board
Digital Portable Interactive Whiteboard Finger Touch Magnetic Board
Digital Portable Interactive Whiteboard Finger Touch Magnetic Board
Digital Portable Interactive Whiteboard Finger Touch Magnetic Board
Digital Portable Interactive Whiteboard Finger Touch Magnetic Board
Specifications
Brand Name :
FLYIN/OEM/COSTA
Model Number :
FP4
Certification :
CE,FCC ,ROHS
Place of Origin :
China
Payment Terms :
T/T, Western Union, MoneyGram,Alibaba Trade Assurance
Calibration :
Automatic(5s) / Manual (25/36 points)
Multi-touch :
Ten points touch, write and eraser can do together.
Latency :
<30ms
Filter :
Software auto-control, enhance stability.
Minimum Active Size :
40 inch
Technology :
Laser Image Calibration Technology
Description
Digital Portable Interactive Whiteboard Finger Touch Magnetic Board
Product Overview

The FP4 Digital Portable Interactive Whiteboard features advanced Laser Image Calibration Technology, creating a versatile touch-enabled surface for presentations, education, and collaborative work environments.

Technology Overview

The FP4 Board consists of two main components: an emitter and sensor. The emitter attaches to any flat surface and projects an invisible infrared laser curtain approximately 1mm above the projection surface. When fingers or non-transparent objects interact with this virtual surface, reflected light is detected by the sensor, enabling precise cursor positioning through advanced computational algorithms.

Available Sizes
  • Standard: 100 inch
  • HD: 150 inch
  • HD Extended: 150-260 inch
Key Features
  • Laser Image Calibration Technology (LICT) - No computer or projector adjustment required
  • Finger touch capability with active size up to 100"
  • Compact and portable design (total weight under 500g)
  • Automatic calibration within 5 seconds (95%+ success rate)
  • 10-point multi-touch support
  • Comprehensive gesture recognition
  • High cost-effectiveness
  • Minimum throw ratio: 0.15
Functional Advantages
  • High stability with advanced light-interference algorithms
  • Full-screen utilization with minimal border space
  • Extensive gesture recognition support
Digital Portable Interactive Whiteboard Finger Touch Magnetic Board Digital Portable Interactive Whiteboard Finger Touch Magnetic Board
Technical Specifications
Calibration Automatic (5s) / Manual (25/36 points)
Gesture Recognition Education Software: Single finger writing, palm erase, two-finger move, zoom in/out, palm spotlight, double slap to desktop. Windows: Maximize/minimize windows, picture zoom/rotate, scroll bar, window display, shift windows.
Multi-touch Ten points touch, simultaneous writing and erasing
Latency <30ms
Filter Software auto-control for enhanced stability
Minimum Active Size 40 inch
Maximum Active Size 100 inch (light-proof environment, excludes double screen)
Technology Laser Image Calibration Technology
Positional Accuracy ±1 Pixel (Resolution: 4096×4096)
Aspect Ratio 4:3; 16:9; 16:10
Projection Ratio Ultra short throw: 0.15 (0.35m), 0.21 (0.45m), 0.28 (0.45m); Short throw: 0.34 (0.54m); Long throw: 0.86 (1.4m), 1.34 (2.2m) - based on 80" 4:3 projection screen
Laser Beam 2 units
Laser Wave 940nm
Power 5w
Laser Beam Power 280mw×2
Power Requirements 3.3V/2A
Signal Refresh Rate 120fps
Connectivity Sensor to computer via USB cable; Wireless emitter-sensor communication; Emitter requires power only
Weight 0.5kg
OS Requirements Windows 7, Windows 8, Windows 10, Android
Software Calibration software (driver) and GLboard (education software)
Certification CE, FCC
Warranty 2 years
Package Contents Sensor, Emitter, Mounts, USB cable (12m), Pointer, Power Adapter, Manual
