5108-HD Condom Electrical Leak Tester for RoHS Compliance Testing
5108-HD Condom Electrical Leak Tester for RoHS Compliance Testing
5108-HD Condom Electrical Leak Tester for RoHS Compliance Testing
5108-HD Condom Electrical Leak Tester for RoHS Compliance Testing
Specifications
Brand Name :
HAIDA
Model Number :
5108-HD
Certification :
CE
Place of Origin :
china
MOQ :
1set
Price :
Negotiable
Payment Terms :
L/C,D/A,T/T,D/P,Western Union,MoneyGram
Supply Ability :
30 Sets per Month
Delivery Time :
20 days after order confirmed
Packaging Details :
each set protected with resin fiber and PP film, then put into Strong wooden case with operation man
Minimum Detection Limit :
Pb≤5ppm, Cd/Cr/Hg/Br≤2ppm, Cl≤50ppm
Peak Area Reproducibility :
< 0.5% RSD
Rsd :
≤1.5%
Grating Lines :
1800
Detector :
Photomultiplier Tube
Detection Object :
Solid
Content Analysis Range :
1ppm~99.99%
Test Object :
Powder, Solid, Liquid
Resolution :
0.1nm
Test Time :
100-300 seconds (adjustable)
Sensitivity :
0.001 Abs
Cooling Rate :
< 3.5min (450˚C to 50˚C)
Analysis :
4 phthalates in RoHS2.0 directive
Model :
1234
Spectral Bandwidth :
0.1nm, 0.2nm, 0.4nm, 0.7nm, 1.0nm, 2.0nm
Description
PRODUCT DESCRIPTION

Condom electrical leak detector is suitable for rubber sleeves and condom pinhole leakage tests.

DESIGN STANDARD

GB7544,ISO 4074,ISO 25841

FEATURES
  • Comfortable and safe operation, compact structure, easy maintenance, fast and reliable operation;
  • The instrument supports water leakage test (visual observation method) and electrical inspection method dual mode;
  • The instrument uses replaceable measuring heads, male condom measuring heads and female condom measuring heads;
  • It has 10 independent automatic lifting test heads, and the test data is automatically transmitted to the computer;
  • Configured with data acquisition port for printing and saving
  • The test range is wide and can meet samples of various sizes;
PRINCIPLE
Electrical inspection method:

Condoms are checked for pinholes using an electronic shielding method. Condoms without pinholes are like insulators, and the current will not form a loop and flow through the condom. On the contrary, condoms with pinholes will form a current loop.

Visual inspection method:

Condoms are filled with a certain amount of water, and the condom is manually visually observed to see if it is leaking.

TECHNICAL PARAMETERS
Items Parameters
Test position 10
Water temperature (10℃～40℃), time (10±2)s
Injection volume (50mL～1000mL) ±10mL (automatic water injection,water injection volume can be set)
DC voltage (10±0.1)V
Voltmeter accuracy ±0.3mV
Precision resistance (10±0.5)kΩ
Dimensions 1000 mm (L) *450 mm (W) * 1600 mm (H)
Weight Appox. 180kg
Configuration list Main unit Workstation, Measuring electrode rod A set of male condom test heads A set of female condom K.2 leak test stand
HAIDA INTRODUCTION

Founded in 2004, Haida ® is the recognized Dongguan, China market leader in the testing equipment industry, having four main manufacture series: Accelerated Environmental Series (AES), Universal Tensile Machine (UTM), Paper & Packaging (P&P), Foam, Furniture & Optical (FFO), also involved in Textile & Shoes & Leather, Luggage, Baby carriage & toys, and optical testing equipment.
