ASTM D92 LED screen SD3536S Semi-automatic Open Flash Point Tester
ASTM D92 LED screen SD3536S Semi-automatic Open Flash Point Tester
ASTM D92 LED screen SD3536S Semi-automatic Open Flash Point Tester
ASTM D92 LED screen SD3536S Semi-automatic Open Flash Point Tester
ASTM D92 LED screen SD3536S Semi-automatic Open Flash Point Tester
ASTM D92 LED screen SD3536S Semi-automatic Open Flash Point Tester
ASTM D92 LED screen SD3536S Semi-automatic Open Flash Point Tester
ASTM D92 LED screen SD3536S Semi-automatic Open Flash Point Tester
Specifications
Brand Name :
Shengtai Instrument
Model Number :
SD3536S
Place of Origin :
China
MOQ :
1 carton
Payment Terms :
T/T
Supply Ability :
20 cartons per week
Delivery Time :
7-15 working days
Power supply :
AC(220±10%)V, 50Hz.
Heating device :
electric furnace heating, no flame, explosion-proof, power 0-600W continuous adjustable.
Temperature control :
room temperature ~ 400℃, grading 2℃, technical conditions in line with the technical conditions of liquid thermometer used in petroleum products test GB/T514 provisions
Temperature display :
LED screen shows temperature parameters. The range is 0ºC~400ºC, accuracy is 0.1ºC.
Ignition device :
(1) Ignition source: gas (or other civil combustible gas, the same below); (2) Nozzle aperture: 0.6 〜 0.8 mm.
Temperature sensor :
RTD, PT100
Ambient temperature :
(-10~50)ºC
Description

SD3536S Semi-automatic Open Flash Point Tester

SD3536S Semi-automatic open flash point tester is in according to the standard of the People's Republic of China GB/T3536-2008 "petroleum products determination of flash point and burning point Cleveland KaiKouBei act the requirements stipulated in the design and manufacture, is suitable for the determination of the fuel oil and oil products outside the mouth flash point is below 79 ℃, flash point and burning point also support GB/T1671-2008 plasticizer on the determination of flash point.

ASTM D92 Semi-automatic Open Flash Point Tester

Semi-Automatic Cleveland Open Cup Flash Point Tester

ASTM D92 Semi-Automatic Cleveland Open Cup Flash Point Tester GB/T3536-2008

SD3536Semi-automatic Cleveland Open-Cup Flash Point Tester

Main technical parameters and indexes

1. Power supply AC(220±10%)V, 50Hz.
2. Heating device electric furnace heating, no flame, explosion-proof, power 0-600W continuous adjustable.
3. Temperature control room temperature ~ 400℃, grading 2℃, technical conditions in line with the technical conditions of liquid thermometer used in petroleum products test GB/T514 provisions
4. Temperature display LED screen shows temperature parameters. The range is 0ºC~400ºC, accuracy is 0.1ºC.
5. Ignition device

(1) Ignition source: gas (or other civil combustible gas, the same below);

(2) Nozzle aperture: 0.6 〜 0.8 mm.
6. Temperature sensor RTD, PT100
7. Ambient temperature (-10~50)ºC
8. Relative humidity ≤85%
9.Maximum power consumption 650W
10. Package size: 380mm * 290m * 260mm Weight: 10kg

ASTM D92 LED screen SD3536S Semi-automatic Open Flash Point Tester

Packing List

S/N NAME UNIT Quantity Remarks
1 Open flash point meter set 1
2 Special brass oil cup piece 1
3 Special thermometer piece 1
4 instructions copy 1
5 Certificate of conformity warranty card copy 1

Customers need to provide their own: coal gas source and coal gas source required pressure reducing valve

The thermometer of the open flash point meter is made of mercury and may not allowed be transportable,maybe purchase it locally
