ASTM D1298 Touch-screen temperature control Semi-automatic Petroleum Density Meter
ASTM D1298 Touch-screen temperature control Semi-automatic Petroleum Density Meter
ASTM D1298 Touch-screen temperature control Semi-automatic Petroleum Density Meter
ASTM D1298 Touch-screen temperature control Semi-automatic Petroleum Density Meter
Specifications
Brand Name :
Shengtai Instrument
Model Number :
SH102A
Place of Origin :
China
MOQ :
1 carton
Payment Terms :
T/T
Supply Ability :
20 cartons per week
Delivery Time :
7-15 working days
Power supply :
AC 220V±10%, 50Hz.
Bath volume :
Ф250×300 mm.
Test tube capacity :
500 mL.
Heating power :
700 W
Temperature control range :
Ambient temperature ~ 80℃ (or 5℃ ~ 80℃ with optional cooling system)
Temperature control accuracy :
±0.1℃.
Description

SH102A Semi-automatic Petroleum Density Meter

This instrument is designed and manufactured in accordance with the requirements specified in GB/T 1884 Petroleum and liquid petroleum products—Determination of density (hydrometer method). It is a newly developed liquid petroleum product density tester, suitable for determining the density of crude oil and liquid petroleum products.

Compliant Standards

GB/T 1884 Petroleum and liquid petroleum products—Determination of density (hydrometer method)

ASTM D1298,GB/T 2281-2008 Coking oil products—Determination of density,GB 36170-2018 Crude oil

SH 0068 Engine coolants and concentrates—Determination of density or relative density (hydrometer method)

GB/T 4472 Chemical products—Determination of density and relative density.

Main Technical Features & Parameters

● Touch-screen temperature control.

● Equipped with hard glass bath and electric stirring device, ensuring clear sample observation and uniform temperature in the bath.

● Power supply: AC 220V±10%, 50Hz.

● Bath volume: Ф250×300 mm.

● Test tube capacity: 500 mL.

● Heating power: 700 W.

● Temperature controller:

● Temperature control range: Ambient temperature ~ 80℃ (or 5℃ ~ 80℃ with optional cooling system)

● Temperature control accuracy: ±0.1℃.

● Temperature sensor: Industrial platinum resistance, Pt100.

● Number of measuring holes: 2.

● Set of 10 density hydrometers:Measuring range: 600–1010 kg/m³,Graduation: 0.5,Total ● length: 300 mm.

● Dimensions: 320 × 380 × 530 mm.

● Net weight: 12 kg.
