Laboratory Jaw Crusher Machine for Mining Ore Crushing
Laboratory Jaw Crusher Machine for Mining Ore Crushing
Laboratory Jaw Crusher Machine for Mining Ore Crushing
Laboratory Jaw Crusher Machine for Mining Ore Crushing
Specifications
Payment Terms :
T/T,L/C
Max Feeding Size :
≤50 mm / ≤80 mm
Voltage :
Three Phase 380V 50Hz
OEM&ODM :
Available
Delivery Time :
1-3 working days
Output Size :
5–15 mm / 6–25 mm / 8–35 mm (Adjustable)
Place of Origin :
China
Application :
Mining, Mineral Processing, Geological Testing
Motor Power :
2.2 kW / 2.2 kW / 3 kW
Certification :
Iso 9001
Packaging Details :
Standard export packing is provided, and customized packing is available upon request.
Capacity :
45–550 kg/h / 60–850 kg/h / 300–2000 kg/h
MOQ :
1
Model :
SZ100×60 / SZ100×100 / SZ125×100
Price :
Negotiate
rushing Material :
Ore, Rock, Mineral Samples, Stone
Brand Name :
Y&X
Product Name :
Laboratory Jaw Crusher
Description
Laboratory Jaw Crusher Machine for Mining Ore Crushing
Y&X Laboratory Jaw Crusher is specially designed for crushing various mineral ores and rock samples in mining laboratories, geological laboratories and research institutions. Adopting a double-toggle jaw crushing structure, this machine provides strong crushing force, stable performance and uniform particle size.
The equipment features a reasonable structure, adjustable discharge size, reliable operation, low noise and easy maintenance. It is an ideal crushing solution for mineral sample preparation, laboratory testing and small-scale material processing.
Laboratory Jaw Crusher Machine for Mining Ore Crushing
Main Features
  • Strong Crushing Performance - High-strength crushing chamber provides efficient crushing capability for different types of ores and rocks.
  • Adjustable Output Size - The discharge opening can be adjusted according to different testing requirements.
  • Stable & Reliable Operation - Optimized structure ensures smooth running, low vibration and long service life.
  • Wide Application Range - Suitable for mining, metallurgy, geology, mineral processing laboratories and scientific research.
  • Easy Maintenance Design - Compact structure allows convenient operation and maintenance.
Technical Parameters
Model SZ100×60 SZ100×100 SZ125×100
Jaw Plate Material High Chromium Alloy High Chromium Alloy High Chromium Alloy
Feeding Size ≤50 mm ≤80 mm ≤80 mm
Discharge Size 5-15 mm Adjustable 6-25 mm Adjustable 8-35 mm Adjustable
Capacity 45-550 kg/h 60-850 kg/h 300-2000 kg/h
Crushing Speed 600 r/min 600 r/min 600 r/min
Motor Power 2.2 kW 2.2 kW 3 kW
Voltage 380V/50Hz 380V/50Hz 380V/50Hz
Dimension 700×570×1250 mm 700×570×1250 mm 700×570×1250 mm
Weight Approx. 250 kg Approx. 255 kg Approx. 260 kg
Applications
  • Mining laboratory sample preparation
  • Geological exploration testing
  • Mineral processing experiments
  • Metallurgical research
  • Ore crushing before grinding
  • Rock and stone analysis
  • University and research institute laboratories
Laboratory Jaw Crusher Machine for Mining Ore Crushing
Why Choose Y&X Laboratory Crusher?
12+ Years Experience in Mining Laboratory Equipment
Y&X provides complete solutions for mining laboratories, including crushing, grinding, flotation, screening and mineral testing equipment. With practical experience from mineral processing laboratories and mine sites, Y&X understands customers' testing requirements and provides reliable equipment selection and technical support.
Frequently Asked Questions
What materials can this jaw crusher crush?
This laboratory jaw crusher can crush various ores, rocks and mineral samples, including gold ore, copper ore, iron ore, lead-zinc ore and other geological samples.
Can the output particle size be adjusted?
Yes. The discharge size can be adjusted according to different laboratory testing requirements.
Is this crusher suitable for mining laboratories?
Yes. It is designed for mineral sample preparation and widely used in mining companies, geological laboratories and research institutions.
What power supply does the machine require?
Standard power supply is three-phase 380V/50Hz. Customized voltage is available according to customer requirements.
