XFDⅣ Single Tank Flotation Machine with Frequency Conversion Technology and Easy Adjustment for Laboratory Use
XFDⅣ Single Tank Flotation Machine with Frequency Conversion Technology and Easy Adjustment for Laboratory Use
Specifications
Type :
XFD type, XFDⅣ type
Technology :
frequency conversion technology
Weight :
30kg
Advantage :
easy adjustment
Scraper speed :
15、30r/min
Name :
flotation machine
Packaging Details :
Standard export packing is provided, and customized packing is available upon request.
Delivery Time :
1-3 working days
Brand Name :
Y&X
Model Number :
flotation machine
Certification :
Iso 9001
Place of Origin :
China
MOQ :
1
Price :
Negotiate
Payment Terms :
T/T,L/C
Model :
single tank
Purpose :
gold, building materials
Description
XFDⅣ Single Tank Flotation Machine Laboratory Flotation Cell
Product Overview

XFD type and XFDⅣ type series single tank flotation machines are designed for laboratory use and research applications. These machines are essential tools in mineral processing laboratories and scientific research units across various industries including geology, metallurgy, gold, building materials, coal, and chemical mining operations.

Key Features
  • Frequency conversion technology for stepless speed regulation
  • Digital display for easy adjustment and accurate monitoring
  • External inflation device for enhanced performance
  • Improved scraper device with stepless speed regulation
  • Automatic water replenishment and delivery systems
  • Enables complete flotation automation
Technical Specifications
No. Project Unit Specifications and Parameters
1 Impeller Speed r/min XFD: 2130,2310,2590 | XFDⅣ: 0-2800
2 Scraper Speed r/min XFD: 15,30 | XFDⅣ: 0-30
3 Scraper Motor r/min 302A 0-30r/min
4 Heater w 250w (Configure according to user needs)
5 Diameter of Impeller mm Φ41 | Φ45 | Φ55 | Φ60
6 Feeding Particle Size mm 0.05-0.2
7 Spindle Motor Model Power r/min XFD: DYS16-8 2800(r/min) 220v 75w(Three) | XFDⅣ: YS-5612 2800(r/min) 220v 90w(Three)
8 Dimensions mm XFD: 502*263*628 | XFDⅣ: 580*350*890
9 Weight kg XFD: 30 | XFDⅣ: 30
Company Profile

Y&X Beijing Technology Co., Ltd., established in 2014 and headquartered in Beijing, China, has evolved into a professional enterprise integrating scientific research, design, new product development, production and manufacturing with strong technical capabilities.

As part of a family group, our mission from inception has been to expand overseas markets and provide comprehensive professional solutions for international mining companies. We specialize in the research and supply of mineral processing reagents and equipment, including both industrial mineral processing equipment and laboratory mineral processing equipment.

Our products are widely used across multiple industries including metallurgy, geology, petroleum, coal, chemicals, building materials, environmental protection, and non-ferrous and non-metallic mining operations. Our equipment serves research departments in dressing plants and mineral processing laboratories in colleges and universities worldwide.

Our laboratory mineral processing equipment portfolio includes crushing, grinding, screening, grading, magnetic separation, flotation, assay, sample preparation, leaching, analysis-electrolysis, shaking table, chute, and other laboratory and gravity separation equipment.

Our products have established strong market presence in Russia, Mongolia, Chile, Australia, Zimbabwe, Thailand, Laos, Indonesia, Tanzania, Nigeria, and other countries and regions.

The enterprise has achieved ISO9001 quality management system certification, ensuring our product quality conforms to relevant national and enterprise technical standards.
