Automatic High-Temperature Impact Tester Flexural Strength Testing Machine
Automatic High-Temperature Impact Tester Flexural Strength Testing Machine
Automatic High-Temperature Impact Tester Flexural Strength Testing Machine
Automatic High-Temperature Impact Tester Flexural Strength Testing Machine
Specifications
Brand Name :
Lonroy
Model Number :
LRKZ-II
Certification :
Includes Calibration Certification
Place of Origin :
China
MOQ :
1
Price :
Negotaible
Payment Terms :
L/C,D/A,D/P,T/T,Western Union,MoneyGram
Supply Ability :
200
Delivery Time :
5-8 work days
Packaging Details :
wooden package
Power Supply :
380 V, 12 kW
Loading Capacity :
10,000N or 20,000N
Heating Elements :
1400°C/1600°C
Heating rate :
0-20°C/min
Warranty :
1 Year
Description

Automatic High-Temperature Impact Tester Flexural Strength Testing Machine

1.Description:

This instrument is applicable to the test methods for high-temperature flexural strength of refractory materials as per GB3002-2004, and the test methods for high-temperature flexural strength of carbon-containing refractory materials as per GB/T13243-1991. It meets the requirements for high-temperature flexural tests of refractory products, carbon-containing refractory materials, dense refractory castables, ceramic rollers and other ceramics and silicate products. Equipped with an automatic sample loading device, it can continuously load samples. One heating test can handle 4 to 6 samples. The instrument is connected to a computer for automatic testing, data processing. The structure is simple, the force application is stable, maintenance is convenient, and the data is accurate and reliable.

2.Technical Parameter

Parameter Specification
Max. Temperature Configurable: 1400°C or 1600°C
Temperature Control Programmable microcomputer control
Heating rate: 0-20°C/min adjustable
Accuracy: ±1°C
Sample Standards
- GB3002-2004 Shaped 150×25×25mm (L×W×H) ×4 pcs
Span: 125±2 mm
- GB3002-2004 Unshaped 160×40×40mm (L×W×H) ×4 pcs
Span: 125±2 mm
- GB/T13243-1991 Carbon (125-130)×25×25mm (L×W×H) ×6 pcs
Span: 100±2 mm
Loading Capacity Configurable: 10,000N or 20,000N
Automation Adjustable loading rate
Automatic sample feeder (4/6 samples per test)
Data Processing Computerized data analysis with printable reports
Power Supply 380V AC, 12 kW
Heating Elements 1400°C: Silicon carbide (SiC) rods
1600°C: Molybdenum disilicide (MoSi₂) rods
Optional Protection Argon/Nitrogen atmosphere for carbon-containing samples
