High-Temperature Reheating Linear Change Box Reburning Test Furnace
High-Temperature Reheating Linear Change Box Reburning Test Furnace
High-Temperature Reheating Linear Change Box Reburning Test Furnace
High-Temperature Reheating Linear Change Box Reburning Test Furnace
Specifications
Brand Name :
Lonroy
Model Number :
LRSL-02
Certification :
Includes Calibration Certification
Place of Origin :
China
MOQ :
1
Price :
Negotaible
Payment Terms :
L/C,D/A,D/P,T/T,Western Union,MoneyGram
Supply Ability :
200
Delivery Time :
5-8 work days
Packaging Details :
wooden package
Power Supply :
380 V, 50 Hz
Max. Temperature :
1600 °C
Heating Rate :
0-10 °C/min
Chamber Dimensions :
510 × 250 × 210 mm
Warranty :
1 Year
Description

High-Temperature Reheating Linear Change Box Reburning Test Furnace

1.Description:

It is mainly used for detecting the re-crenulation line change performance of refractory materials. It can also be used as a box-type electric furnace for material sintering, melting and heat treatment.

2.Configuration:

Includes 1 electric furnace body, 2 B-type thermocouples, and 1 set of silicon-molybdenum rods.

3.Technical Parameter

Parameter / Feature Specification / Description
Design Integrated controller and furnace body
Temperature Sensor Type B (PtRh-PtRh) thermocouple
Temperature Controller Microcomputer programmable controller
Multi-segment heating curves
AI PID control
Automatic heating, soaking, shutdown
Atmosphere Oxidizing atmosphere
Safety Features Thermocouple break protection & alarm
Current limiting & short circuit protection
Furnace Lining Polycrystalline mullite fiber
High temperature resistance
Low heat capacity
Fast heating rate
Excellent insulation
Max. Temperature 1600 °C
Heating Rate 0-10 °C/min
Temperature Control Accuracy ±1 °C (thermocouple)
Chamber Dimensions (L×W×H) 510 × 250 × 210 mm
(Custom sizes available)
Max. Chamber Temperature Difference < ±5 °C (dual-zone)
Power Supply 380 V, 50 Hz
