Specifications
Type :
Testing Machine
Accuracy Class :
High Accuracy
Accuracy :
----
Brand Name :
LONROY
Place of Origin :
Guangdong, China
Application :
Auto Testing, Laboratory Testing, Lab Testing
customized support :
OEM, ODM, OBM
power :
---
Protection Class :
Ip56
Voltage :
220V Electrical Equipment
warranty :
1 Year
Measurement Accuracy :
±3%
Relative humidity :
≤80%
Dimensions (L * W * H) :
600 * 440 * 720 mm
Power Supply :
220 V, 50 Hz
MOQ :
1
Description

Thermal Storage Coefficient Meter Thermal Conductivity Tester High Accuracy Thermophysical Coefficient Test Machine

Product Description

Product Introduction

This thermal storage coefficient meter is primarily used to measure the thermal conductivity, thermal storage coefficient, specific heat, and thermal diffusivity of lightweight aggregate concrete, homogeneous slabs, lightweight aggregate concrete, colloidal, powdered, and granular materials, both dry and at varying moisture levels. It can simultaneously measure and calculate various thermophysical coefficients under both dry and equilibrium moisture content conditions in a single test.

The thermal storage coefficient meter offers simple operation, high accuracy, and fast testing speed (a single test takes approximately ten minutes). Based on the principle of unsteady heat conduction, it briefly heats the test material, causing the material's temperature to change. Based on the characteristics of this temperature change, the thermal storage coefficient, thermal conductivity, thermal diffusivity, and specific heat of the test material can be calculated by solving the heat conduction differential equation.

Standards

JGJ/T 12-2019 "Technical Specification for Lightweight Aggregate Concrete"

JG158-2004 "Glue Powder Polystyrene Granule External Wall Insulation System"

JG/T283-2010 "Expanded Vitrified Microsphere Lightweight Mortar"

AThermal Storage Coefficient Meter Thermal Conductivity Tester High Accuracy Thermophysical Coefficient Test Machine

Technical Specification

Thermal Storage Coefficient Range

0.01–100 W/(m²·K)

Thermal Conductivity Range

0.001–10 W/(m·K)

Specific Heat Capacity Range

0.01 kJ/(kg·K)

Thermal Diffusivity Range

0.01–×10³ m²/h

Specimen Size

One thin specimen: 20 × 20 × (1.5–3) cm

Two thick specimens

20 × 20 × (4–10) cm

Power Supply

220 V, 50 Hz

Dimensions (L × W × H)

600 × 440 × 720 mm

Operating Conditions

Ambient temperature: 10–35 °C

Relative humidity

≤80%

Room temperature stability

≤±1.5 °C

Measurement Accuracy

±3%

Thermal Storage Coefficient Meter Thermal Conductivity Tester High Accuracy Thermophysical Coefficient Test MachineThermal Storage Coefficient Meter Thermal Conductivity Tester High Accuracy Thermophysical Coefficient Test MachineThermal Storage Coefficient Meter Thermal Conductivity Tester High Accuracy Thermophysical Coefficient Test MachineThermal Storage Coefficient Meter Thermal Conductivity Tester High Accuracy Thermophysical Coefficient Test Machine
