Specifications
Brand Name :
Lonroy
Place of Origin :
China
MOQ :
1
Voltage :
110~220V
Frequency :
50/60Hz
Power Consumption :
48W (standby), 2000W (heating)
Protection Class :
IP56
Machine Dimensions :
800 × 380 × 410 mm
Machine Weight :
44 kg
Coating Speed :
1-3 meters/minute
Coating Length :
10-450 mm
Temperature Range :
Room temperature to 160℃
Coating Uniformity :
±4 microns
Coating Width :
300 × 450 mm
Coating Thickness :
0.005-5 mm (wet film)
Line Rod Dimensions :
Diameter 10 × Length 400 mm
Workbench Material :
Aluminum alloy + glass
Knife Material :
Alloy stainless steel
Certification :
ISO ASTM CE
Price :
Negotaible
Packaging Details :
Wooden package
Delivery Time :
5-8 work days
Payment Terms :
L/C,D/A,D/P,T/T,Western Union
Supply Ability :
200
Description

Laboratory Small Coating Machine Compact Lab Coating Test Equipment Laboratory Scale Mini Coater

Product Description

Product Overview

The laboratory small coating machine uses all high-quality components and has a favorable price, and has been favored by many multinational enterprise research institutions and many well-known universities at home and abroad. It ensures the coating effect by controlling the speed and stable pressure, and guarantees the uniformity and stability of the coating. The main feature of the laboratory small coating machine is that it can be used for coating experiments on various materials such as paper, plastic, metal, PVC, PET, fabric, aluminum alloy plates, etc.

Advantage

The main advantage of the laboratory small coating machine is that it can repeatedly and continuously produce smooth, flat and flawless test samples. It is convenient for the experimenters to precisely coat on different substrates, reducing and eliminating errors caused by different coating speeds and pressures due to human factors. The coating head uses a special scraper to imitate the head of a large coating machine to ensure that the products obtained from the experiment are consistent with the quality of the production coating. The coating head can be quickly opened at 90 degrees to facilitate cleaning the scraper after each experiment.


Laboratory Small Coating Machine Compact Lab Coating Test Equipment Laboratory Scale Mini Coater

Technical Specification

Control System

Independently developed by Lonroy / PLC touch screen

Coating Method

Integrated knife/line rod (separate for individual coating)

Knife Elevator

Rear flip type (convenient for cleaning)

Coating Speed

Digitally set, 1-3 meters/minute

Length Setting

Digitally set, 10-450 mm

Temperature Control

Room temperature to 160℃ (constant temperature achievable)

Leveling Device

Equipped with leveling rods; material is flattened first before coating

Workbench Material

Aluminum alloy + glass (removable)

Clamping Tools

Automatic clamping tools

Coating Uniformity

±4 microns (depending on the material's flatness)

Width

300×450 mm

Coating Thickness

0.005-5 mm (wet film)

Machine Volume

Length 800 × Width 380 × Height 410 mm (for reference)

Machine Weight

Net weight: 44 kg (for reference)

Line Rod Device

Comes with a line rod device (line rods optional; one line rod per thickness)

Line Rod Weights

With two adjustable counterweights

Line Rod Dimensions

Diameter 10 × Length 400 mm (universal)

Knife Material

Alloy stainless steel

Power Source

Voltage: 110~220V, 50/60Hz

Power

48W (standby), 2000W (heating)
