Laboratory Coating Equipment PLC Touch Screen Lab Heated Model Coating Apparatus Coating Test Machine
Laboratory Coating Equipment PLC Touch Screen Lab Heated Model Coating Apparatus Coating Test Machine
Laboratory Coating Equipment PLC Touch Screen Lab Heated Model Coating Apparatus Coating Test Machine
Laboratory Coating Equipment PLC Touch Screen Lab Heated Model Coating Apparatus Coating Test Machine
Laboratory Coating Equipment PLC Touch Screen Lab Heated Model Coating Apparatus Coating Test Machine
Laboratory Coating Equipment PLC Touch Screen Lab Heated Model Coating Apparatus Coating Test Machine
Laboratory Coating Equipment PLC Touch Screen Lab Heated Model Coating Apparatus Coating Test Machine
Laboratory Coating Equipment PLC Touch Screen Lab Heated Model Coating Apparatus Coating Test Machine
Laboratory Coating Equipment PLC Touch Screen Lab Heated Model Coating Apparatus Coating Test Machine
Laboratory Coating Equipment PLC Touch Screen Lab Heated Model Coating Apparatus Coating Test Machine
Laboratory Coating Equipment PLC Touch Screen Lab Heated Model Coating Apparatus Coating Test Machine
Laboratory Coating Equipment PLC Touch Screen Lab Heated Model Coating Apparatus Coating Test Machine
Specifications
Brand Name :
Lonroy
Place of Origin :
China
MOQ :
1
Voltage :
110~220V
Frequency :
50Hz
Power Standby :
48W
Power Heating :
2000W
Coating Speed :
1-3 meters/minute
Coating Length :
10-300 mm
Temperature Range :
Room temperature to 160℃
Coating Uniformity :
±4%
Coating Size :
200×300 mm
Coating Thickness :
0.005-5 mm (wet film)
Machine Dimensions :
550×350×350 mm
Net Weight :
28 kg
Winding Rod Dimensions :
Diameter 10 × Length 300 mm
Protection Class :
IP56
Workbench Material :
Aluminum alloy + glass
Certification :
ISO ASTM CE
Price :
Negotaible
Packaging Details :
Wooden package
Delivery Time :
5-8 work days
Payment Terms :
L/C,D/A,D/P,T/T,Western Union
Supply Ability :
200
Description

Laboratory Coating Equipment PLC Touch Screen Lab Heated Model Coating Apparatus Coating Test Machine

Product Description

Product Overview

The laboratory small coating machine uses all high-quality components and has a favorable price, and has been favored by many multinational enterprise research institutions and many well-known universities at home and abroad. It ensures the coating effect by controlling the speed and stable pressure, and guarantees the uniformity and stability of the coating. The main feature of the laboratory small coating machine is that it can be used for coating experiments on various materials such as paper, plastic, metal, PVC, PET, fabric, aluminum alloy plates, etc.

Advantage

The main advantage of the laboratory small coating machine is that it can repeatedly and continuously produce smooth, flat and flawless test samples. It is convenient for the experimenters to precisely coat on different substrates, reducing and eliminating errors caused by different coating speeds and pressures due to human factors. The coating head uses a special scraper to imitate the head of a large coating machine to ensure that the products obtained from the experiment are consistent with the quality of the production coating. The coating head can be quickly opened at 90 degrees to facilitate cleaning the scraper after each experiment.

Note: For low-viscosity and high-precision applications, the ribbon coating machine provides better results; for high-viscosity materials, the scraper coating method is more effective!


Laboratory Coating Equipment PLC Touch Screen Lab Heated Model Coating Apparatus Coating Test Machine

Technical Specification

Control System

Lonroy independently developed / PLC touch screen

Coating Method

Knife and wire rod integrated (separate coating for each)

Knife Lifting

Pull-up type (convenient for cleaning when the knife is separated)

Coating Speed

Digitally set, 1-3 meters/minute

Length Setting

Digitally set, 10-300 mm

Temperature Control

Room temperature to 160℃ (constant temperature possible)

Leveling Device

With leveling rods; the material is flattened first before coating

Workbench Material

Aluminum alloy + glass (removable)

Coating Uniformity

±4% (depending on the flatness of the material)

Coating Size

200×300 mm

Coating Thickness

0.005-5 mm (wet film)

Machine Dimensions

Length 550 × Width 350 × Height 350 mm (reference)

Machine Weight

Net weight: 28 kg (reference)

Winding Rod Device

Built-in winding rod device (winding rods are optional, one rod for each thickness)

Winding Rod Weights

Equipped with two counterweight weights (adjustable)

Winding Rod Dimensions

Diameter 10 × Length 300 mm (universal)

Scraping Knife Material

Alloy stainless steel

Power Source

Voltage: 110~220V, 50Hz

Power

48W (standby); 2000W (heating)
