Specifications
Type :
Testing Machine
Accuracy :
1%
Brand Name :
Lonroy
Place of Origin :
Guangdong, China
customized support :
OEM, ODM, OBM
power :
100W, Electronic
Protection Class :
IP66
Voltage :
220 V
warranty :
1year
Standard :
ASTM D1003/D1044,ISO13468/ISO14782
Product name :
Haze Meter
Model :
TH-100
MOQ :
1
Price :
CN¥9,797.06
Description

TH-100 Haze Meter ASTM D1746 opacity tester for Plastic film

Part 1. Instrument Advantages

1). It conforms to both ASTM and ISO international standards ASTM D 1003,ISO 13468,ISO 14782, JIS K 7361 and JIS K 7136.

2). Instrument is with a calibration certification from a third party laboratory.

3). No need to do warm-up, after instrument is calibrated, it can be used. And measurement time is only 1.5 seconds.

4). Three kinds of illuminants A,C and D65 for haze and total transmittance measurement.

5). 21mm test aperture.

6). Open measurement area, no limit on sample size.

7). It can realize both horizontal and vertical measurement to measure different kinds of materials such as sheets, film, liquid, etc.

8). It adopts LED light source whose lifetime can reach 10 years.

TH-100 Haze Meter ASTM D1746 opacity tester for Plastic film

Part 2. Technical Data

Model

Haze Meter TH-100

Character

ASTM D1003/D1044 and ISO13468/ISO14782 standard for haze measurement and light transmittance measurement.

Open measurement area and samples can be tested vertically and horizontally. Application: glass, plastic, film, display screen, packaging and other industries.

Illuminants

D65,A,C

Standards

ASTM D1003/D1044, ISO13468/ISO14782, GB/T 2410,JJF 1303-2011, CIE 15.2, GB/T 3978, ASTM E308, JIS K7105, JIS K7361, JIS K 7136

Test Parameter

ASTM and ISO (HAZE),Transmittance (T)

Test Aperture

21mm

Instrument Screen

5 inches color LCD screen

Haze Repeatability

Φ21mm aperture, Standard Deviation: within 0.08(when a haze standard with value 40 is measured 30 times at 5-second interval after calibration)

Transmittance Repeatability

≤0.1 unit

Geometry

Transmittance 0/D (0 degree illumination, diffused receiving)

Integrating Sphere Size

Φ154mm

Light Source

400~700nm full spectrum LED light source

Test Range

0-100%

Haze Resolution

0.01 unit

Transmittance Resolution

0.01 unit

Sample Size

Open space, no size limit

Data Storage

20,000 pcs of samples

Interface

USB

Power Supply

DC12V (110-240V)

Working Temperature

+10 – 40 °C (+50 – 104 °F)

Storage Temperture

0 – 50 °C (+32 – 122 °F)

Size

L x W x H: 310mmX215mmX540mm
