Specifications
Brand Name :
LONROY
Place of Origin :
Guangdong, China
customized support :
OEM, ODM, OBM
warranty :
1year
Blade length :
19mm
Blade height :
3mm
Blade thickness :
0.24mm
MOQ :
1
Description

ASTM D1693 Plastics Environmental Stress Cracking Tester

Overview:

Nyk-06 environmental stress cracking tester is mainly used to measure the stress cracking capacity of ethylene - based resins and plastics.

Ii. Applicable Standards:

GB/T1842, GB/T2951.41, ASTM D1693

ASTM D1693 Plastics Environmental Stress Cracking Tester

Instrument Features:

1. The shell of this product is made of high-quality cold-rolled plate with plastic-sprayed surface.

2. The inner tank, upper cover and test-tube stand are made of 304 stainless steel, which are resistant to corrosion and durable.

3. Sample retainer brass material, machined slotted (non-stainless steel plate bending).

4, PID special temperature control instrument table, accurate temperature control, stable performance, easy to operate.

ASTM D1693 Plastics Environmental Stress Cracking Tester

Technical Parameters:

Adjustable temperature range

room temperature -100℃

Temperature control accuracy

±0.5℃

Blade length

19mm

Blade height

3mm

Blade thickness

0.24mm

Notch depth

0.3-0.65mm

Sample specifications

length: 38±2.5mm, width: 13±0.8mm, height: 1.75-3.00mm

Specimen retainer width

12±0.05mm, 11.75±0.05mm (optional)

Tank size

420*305*375mm (length * width * height)

Overall dimension

605*330*610mm (length * width * height)

thermal medium

pure water

Ambient temperature

10-40℃

Power supply

220V 50Hz

Heating power

3KW

ASTM D1693 Plastics Environmental Stress Cracking Tester

Configuration List

Serial Number

Name

Units

Quantity

Remark

1

Thermostatic Bath

PCS

1

2

Test Tube Stand

PCS

1

8 station, expandable

3

Nick Device

PCS

1

4

Test Tube

PCS

3

5

Cutting Tool For Processing Sample

PCS

1

38* 13mm

6

Sample Retainer

PCS

3

1. There are two options for the width of the inner slot: 12+ -- 0.05mm;11.75 + 0.05 mm

2. A maximum of 10 samples can be placed in each sample cage

7

Sample Bending Device

PCS

1

8

Sample Transfer Tool

PCS

1

9

Blade

PCS

3

10

Specification

PCS

1

11

Packing List

PCS

1

12

Certificate

PCS

1

ASTM D1693 Plastics Environmental Stress Cracking TesterASTM D1693 Plastics Environmental Stress Cracking TesterASTM D1693 Plastics Environmental Stress Cracking TesterASTM D1693 Plastics Environmental Stress Cracking TesterASTM D1693 Plastics Environmental Stress Cracking Tester
