Specifications
Brand Name :
LONROY
Place of Origin :
Guangdong, China
customized support :
OEM, ODM, OBM
power :
Electronic
warranty :
1 Year
Model Number :
LR-643
Product name :
lithium Mineral Analyzer
MOQ :
1
Description

Lithium Mineral Analyzer/Lithium Mine Tester Machine ICP Emission Spectrometer ICP Emission Spectrometer ICP Emission Sp

lithium Mineral Analyzer/Lithium Mine Tester Machine

1. Field of use

1) Detection of lithium ores such as spodumene, feldspar, lepiolite, lithiumite, salt lake lithium, lithium iron carbonate, etc.; Cement, glass, ceramics and refractory materials;

2) Fertilizer and soil testing;

3) Testing of pharmaceutical and beverage industries;

4) Testing of petroleum, metallurgy, mining and chemical products;

5)Testing of some alkaline metals in hospitals, teaching and other fields.

2. Principle introduction

LR-643 lithium ore analyzer is an analytical instrument based on emission spectrum. Including: gas and flame combustion part, optical part, photoelectric converter and detection recording part. The process is that the sample is sprayed into the flame by the atomizer to stimulate the luminescence, and the emission intensity is measured by the detector after splitting the light, the latter is proportional to the content of the element to be measured in the sample. The heat energy of the flame is used to excite the atoms of an element to emit light, and the strength of its spectral energy is detected by the instrument, so as to determine the content of an element in the substance. Due to the limitation of the flame excitation energy, it is generally suitable for the quantitative analysis of alkaline metal elements within a certain concentration range.

lithium Mineral Analyzer/Lithium Mine Tester Machine

1) Detector: photocell

2) Optical splitting element: interference filter

3) Stability: Continuous injection with standard solution, the relative maximum change of the instrument value within 15s is less than 3%

Measured 1 time per minute, measured a total of 6 times the relative maximum change of the instrument value ≤15%

4) Repeatability: Repeat the same standard solution for 7 consecutive independent measurements ≤ 3%

5) Linear error:

K: ≤0.005 mmol/L

Na: ≤0.03 mmol/L

Li: ≤0.005 mmol/L

6) Detection limit:

K: ≤0.004 mmol/L

Na: ≤0.008 mmol/L

Li: ≤0.004 mmol/L

7) Sample suction volume: < 6mL/min

8) Response time: < 8 seconds

9) Test scope:

K : 0 ~ 100 ug/ml

Na: 0 ~ 100 ug/ml

Li : 0 ~ 100 ug/ml

4, the main characteristics of the instrument

1) K and Na are displayed simultaneously; Li and Na switch display;

2) Easy to operate by tapping the button;

3) with flame size pre-selected function;

4) with flame out protection device;

5) With RS232 interface, can be connected to the printer and PC software;

6) With moisture separator.
