Specifications
Type :
Testing Machine
Accuracy :
±1%
Brand Name :
LONROY
Place of Origin :
Guangdong, China
Application :
Auto Testing, Laboratory Testing, Lab Testing
customized support :
OEM, ODM, OBM
power :
---, Electronic
Protection Class :
IP57
Voltage :
220 V, 110 V
warranty :
1year
Logo/graphic design :
Hot Stamping
MOQ :
1
Price :
$1,200
Description

Tensile And Compression Force Gauge Push-Pull Force Meter Motorized Test Stand

1.1 Main usage and scope of application

The AEL-A motorized test stand is an integrated test machine designed to test tensile or compression. It replaces the traditional electric (manual) test machine + digital display test mode, which enhances the accuracy of the test and the convenience of operation. It is suitable for testing such as push-pull force, insertion force and break force test in rubber and plastics, light industrial textiles, building doors and windows, composite materials, wire and cable, auto parts, power machinery, scientific research institutions, etc.



Tensile And Compression Force Gauge Push-Pull Force Meter Motorized Test Stand

1.2 Product Features

1.2.1 7-inch large-screen LCD display;

1.2.2 Real-time force value and displacement display;

1.2.3 Two measurement mode: real-time/peak;

1.2.4 Two working mode: automatic/manual;

1.2.5 Has the function of continuously increasing/decreasing speed;

1.2.6 Has an emergency stop function.

Product model specifications

Model

AE L-A

-2

AEL-A

-3

AEL-A

-5

AEL-A

-10

AEL-A

-20

AEL-A

-30

AEL-A

-50

AEL-A

-100

AEL-A

-200

AEL-A

-300

AEL-A

-500

AEL-A

-1000

Maximum Load

2N

3N

5N

10N

20N

30N

50N

100N

200N

300N

500N

1000N

0.2

kg

0.3kg

0.5kg

1kg

2kg

3kg

5kg

10kg

20kg

30kg

50kg

100kg

0.4

5L

b

0.65Lb

1.1Lb

2.2Lb

4.5Lb

6.5Lb

11Lb

22Lb

45Lb

65Lb

110Lb

220Lb

Load division value

0.001N

0.01N

0.1N

0.0001kg

0.001kg

0.01kg

0.0001Lb

0.001Lb

0.01Lb

Accuracy

±0.5%

±1%

Effective

stroke

400mm

Test speed

1-300mm/min

Working

voltage

AC:110V or AC:220V

Dimension

290mm*500mm*900mm

Net weight

37kg
