High Precision SF6 Dew Point Meter Temperature Instrument Analysis For N2 H2 [KST-V]
High Precision SF6 Dew Point Meter Temperature Instrument Analysis For N2 H2 [KST-V]
High Precision SF6 Dew Point Meter Temperature Instrument Analysis For N2 H2 [KST-V]
High Precision SF6 Dew Point Meter Temperature Instrument Analysis For N2 H2 [KST-V]
High Precision SF6 Dew Point Meter Temperature Instrument Analysis For N2 H2 [KST-V]
High Precision SF6 Dew Point Meter Temperature Instrument Analysis For N2 H2 [KST-V]
Specifications
Brand Name :
KSTONE
Model Number :
KST-V
Certification :
ISO9000
Place of Origin :
Shanghai
MOQ :
1
Price :
$8000-$20000
Payment Terms :
T/T
Supply Ability :
1000
Delivery Time :
7-10 work days
Packaging Details :
Carton / Wooden Box
Dimensions :
340mm×230mm×200mm
Weight :
≤9.5 kg
Sampling Interface :
Self-sealing quick connector
Continuous Operation Time :
>8h
Power Supply :
AC220V±10% (50Hz); 24V lithium battery
Power :
≤70W
Gas to be Measured :
SF6, N2, H2, etc.
Measurement Method :
Fully automatic continuous measurement
Description
Cold Mirror Dew Point Meter KST-V | High-Precision Analysis for N₂, H₂, SF₆
Working Principle

The cold mirror technology measures dew point by condensing water vapor onto a reflective surface when gas temperature drops below the dew point—the saturation temperature of water vapor in the gas. As dew or frost forms, diffuse reflection of incident light activates an electrical signal in the photosensitive device. The detection circuit transmits signal variations and temperature data to the control system, which uses intelligent algorithms to calculate and display dew point temperature (designated as frost point when below 0°C).

Technical Specifications
Parameter Details
Measurement Method Fully automatic continuous measurement
Measured Gases SF₆, N₂, H₂ (specialized for dew point analysis)
Flow Rate 400–800±50 ml/min (digital flow meter display)
Temperature Resolution 0.1°C
Measurement Range 20°C to -62°C
Accuracy ≤±0.3°C
Display Units °C, ppm
Gas Pressure ≤1 MPa
Operating Temperature -20°C to 50°C
Humidity Resistance ≤85% RH (non-condensing environment)
Power Supply AC220V±10% (50Hz) / 24V lithium battery (≥8-hour continuous runtime)
Power Consumption ≤70W
Cooling Source SL micro cooler
Sampling Interface Self-sealing quick connector
Dimensions 340×230×200 mm
Weight ≤9.5 kg
Why Choose Kstone?
  1. Top-tier Technical Authority Standard-setting enterprise | 0.01ppm precision SF6 leak detector | Multiple patents & certifications
  2. One-stop SF6 Solution Range Portable detectors to recovery systems | 100% accredited by national labs
  3. Customizable Turnkey Services Tailored equipment design | On-site installation & debugging
  4. Global Support & Proven Reputation 1000+ global clients | Localized after-sales service
  5. Eco-compliant & Cost-efficient Aligns with EU F-gas Directive | Zero-emission SF6 handling
