NP16260_0104 Schneider ZENcelo KNX Touch Control Panel Glass White for Smart Home Automation System
NP16260_0104 Schneider ZENcelo KNX Touch Control Panel Glass White for Smart Home Automation System
NP16260_0104 Schneider ZENcelo KNX Touch Control Panel Glass White for Smart Home Automation System
NP16260_0104 Schneider ZENcelo KNX Touch Control Panel Glass White for Smart Home Automation System
NP16260_0104 Schneider ZENcelo KNX Touch Control Panel Glass White for Smart Home Automation System
NP16260_0104 Schneider ZENcelo KNX Touch Control Panel Glass White for Smart Home Automation System
Specifications
Timer Function :
Supports scheduling and timer settings
Model Number :
NP16260_0104
Controltype :
Relay-based
Delivery Time :
7 Days
Packaging Details :
Carton
Inputtype :
Binary switch input
MOQ :
5
Load Capacity :
250VA per channel
Payment Terms :
D/P,T/T
Control Type :
Remote and manual control
Brand Name :
Schneider
Switchingfrequency :
Up to 60 Hz
Certification :
CE
Response Time :
Less than 12 hours
Place of Origin :
EU
Description
NP16260_0104 Schneider ZENcelo KNX Touch Control Panel Glass White for Smart Home Automation System
Product Overview

The Schneider Electric NP16260_0104 ZENcelo KNX Touch Control Panel is a premium glass-fronted user interface from the ZENcelo (珍铂) series. This elegant touch panel features capacitive touch technology with a sleek glass surface, providing intuitive control for lighting, shading, and scene management in smart building applications.

The ZENcelo series is known for its minimalist design and premium aesthetics, making it ideal for sophisticated control environments.

Technical Specifications
Touch Technology Capacitive touch with glass surface
Display LED backlit touch indicators with customizable icons
Button Configuration Multiple programmable touch zones
KNX Interface TP (Twisted Pair) with ETS configuration
Communication Objects Up to 100 objects with flexible assignment
Touch Feedback Visual LED feedback with adjustable brightness
Scene Control 8 programmable scenes with visual confirmation
Timer Functions Programmable timer functions via KNX
Operating Voltage 24V DC via KNX bus (no external power required)
Power Consumption ≤0.5W from KNX bus
Faceplate Material Tempered glass with white finish
Frame Compatible with ZENcelo series frames
Mounting Flush mount in standard 55mm wall box
Operating Temperature -5°C to +45°C ambient
Storage Temperature -25°C to +70°C
Humidity 5% to 93% RH (non-condensing)
Dimensions Standard European wall plate size
Certifications CE, KNX certified, EN 60669-2-5
Application Scenarios

This touch panel is perfect for:

Luxury residential projects requiring premium aesthetic control interfaces
High-end hotel suites with elegant glass-finish control panels
Executive offices and boardrooms with sophisticated design requirements
Showroom and exhibition spaces requiring beautiful control interfaces
Modern minimalist interior designs requiring seamless wall integration
Smart home applications where design aesthetics are paramount
