Specifications
Brand Name :
Canaan Kaixinlong
Model Number :
NJP-5000
Place of Origin :
Wenzhou China
MOQ :
1
Price :
67000$
Payment Terms :
T/T, L/C
Packaging Details :
The size of non-fumigated wooden cases varies according to the size of the machine
Output :
5000 Capsules/min
No.of segment bores :
36 (three rows)
Suitable fof capsule :
00#-5#
Total power :
15Kw(standard)
Overall weight :
3200Kgs
Overall diemensions :
1605(+530)mmX1285(+285)mmX2091mm
Description

Overview of the machine:

Automatic Capsule Filling Machine Pharmaceutical Machine Pharmaceutical Technology Pellet Filling Machine

NJP-5000 series capsule filling machine is an automatic capsule filling machine developed by our company by absorbing the advanced technology at home and abroad. The equipment is beautiful in shape, smooth operation, low noise, easy to operate and easy to clean.
The whole machine adopts intermittent rotary mechanism and quantitative filling. Suitable for 00 # -5 # capsule powder and particle filling, and can be equipped with automatic bag feeding machine, vacuum feeding machine, gold inspection machine, polishing machine, hoist and other auxiliary equipment.

Technical parameters:

Output 5000Capsules/min
No.of segment bores 36(Three rows)
Suitable fof capsule 00#-5#
Total power 15Kw(Standard configuration)
Overall weight 3200Kgs
Overall diemensions 1605(+530)mmX1285(+285)mmX2091mm
Noise ≤80DB(A)
Pressure 0.4 ~ 0.7Mpa
Air consumption ≤15m³
Vacuum -0.03 ~ -0.06Mpa
Filling error ±3%~±7%

The machine may make technical improvements without prior notice, and the attached picture shows the options that may be offered.

The process of capsule filling:

Small Pharmaceutical Capsule Machine Manufacturer Pellet Filling Machine

Body cap separation of the empty capsule:

principle
When the empty capsule enters the module hole, the vacuum suction seat rises and is tightened with the lower module. Because the diameter of the small hole of the upper and lower module steps is less than the diameter of the capsule cap and the capsule body respectively; when the vacuum is connected, the capsule body is sucked into the lower module hole, the steps in the upper module die hole block the capsule cap down, and the empty capsule cap is separated.
Small Pharmaceutical Capsule Machine Manufacturer Pellet Filling Machine
Filling-type metering filling:
A-f represents the punching rod of each group, during the interval after the interval time the angle. The powder in the measuring plate mold hole is compacted by each group punching rod once. When the charging rod is lifted from the die hole, the powder box rotates, and the powder on the metering plate will automatically fill the remaining space in the die hole. Fill once, compaction once, until the sixth time, the punching rod will poke the powder column in the mold hole out of the measuring plate, so that it will fall into the empty capsule below, complete the filling work.
Use the relative movement between the scraping powder block and the measuring plate to scrape the excess powder on the surface of the measuring plate to ensure the measurement requirements of the powder column.
The characteristics of the packing-type measurement method
1. The loading amount is accurate, and the difference of the loading amount of> 0.3g is controlled within ± 3%.
2. Adjust the lifting height of the punching rod to fine-tune the dose of drug filling.

Small Pharmaceutical Capsule Machine Manufacturer Pellet Filling Machine
