Specifications
Brand Name :
Canaan Kaixinlong
Model Number :
GZPK-45/55/75
Place of Origin :
Wenzhou China
MOQ :
1
Price :
GZPK-45/103000$ GZPK-55/106000$ GZPK-55/109000$
Model :
GZPK-45/GZPK-55/GZPK-75
Capacity （Tablets/h） :
40500/495000/675000
No.of station :
45/55/75
Max.tablet diameter（mm） :
25/16/13
Rotation speed (r/min) :
75/75/75
Main.tablet diameter（KN） :
100/100/100
Description

Product overview:

Tablet Press For Medical Purposes Double Discharge Automatic High Speed Rotary Tablet Press Tablet Machine Manufacturers

Model GZPK-45/55/75 Double Discharge High Speed Rotary Tablet Press is a product of British Manistee Company. After continuous technological innovation and improvement, it concentrates on the technical characteristics of the domestic automatic high speed rotary tablet press, featuring higher degree of automation, better operability, faster production speed, stronger stability performance and lower working noise. Its technology is located in the domestic leading level.

Technical parameters:

Model GZPK-45 GZPK-55 GZPK-75
Capacity (Tablets/h) 405000 495000 675000
No.of station 45 55 75
Max.tablet diameter(mm) 25 16 13
Rotation speed (r/min) 75 75 75
Main.tablet diameter(KN) 100 100 100
Pre-pressure(KN) 20 20 20
Main.filling depth(mm) 20 20 20
Dia.of.die(mm) 38.1 30.16 24
Length of punch(mm) 133.6 133.6 133.6
Total power(Kw) 7.5(frequency conversion11)
Overall weight(Kg) 4580
Overall diemensions(mm) 1520X1260X1850
Noise ≤75DB(A)

The machine may make technical improvements without prior notice, and the attached picture shows the options that may be offered.

Working principle expansion diagram:
Automatic Types Of Tablet Compression Machine High Speed Rotary

Stamping die:

Automatic Types Of Tablet Compression Machine High Speed Rotary

Working turntable:

The turntable rotates for one week to drive the die to pass through the feeding mechanism, filling mechanism, pressure mechanism, and tablet discharging mechanism in order to complete the process of continuous tablet pressing.
 Automatic Types Of Tablet Compression Machine High Speed Rotary
1.Rotary speed control;
2.On the operation interface, press "speed up", "speed down", key to the turntable for stepless speed regulation

Forced feeder:
Automatic Types Of Tablet Compression Machine High Speed Rotary
