Double Discharge Automatic Tablet Press Machine Compression Tablet Production Equipment
Double Discharge Automatic Tablet Press Machine Compression Tablet Production Equipment
Double Discharge Automatic Tablet Press Machine Compression Tablet Production Equipment
Double Discharge Automatic Tablet Press Machine Compression Tablet Production Equipment
Double Discharge Automatic Tablet Press Machine Compression Tablet Production Equipment
Double Discharge Automatic Tablet Press Machine Compression Tablet Production Equipment
Double Discharge Automatic Tablet Press Machine Compression Tablet Production Equipment
Double Discharge Automatic Tablet Press Machine Compression Tablet Production Equipment
Double Discharge Automatic Tablet Press Machine Compression Tablet Production Equipment
Double Discharge Automatic Tablet Press Machine Compression Tablet Production Equipment
Double Discharge Automatic Tablet Press Machine Compression Tablet Production Equipment
Double Discharge Automatic Tablet Press Machine Compression Tablet Production Equipment
Specifications
Brand Name :
Canaan Kaixinlong
Model Number :
GZPK-45/55/75
Place of Origin :
Wenzhou China
MOQ :
1
Price :
GZPK-45/103000$ GZPK-55/106000$ GZPK-55/109000$
Model :
GZPK-45/GZPK-55/GZPK-75
Capacity （Tablets/h） :
40500/495000/675000
No.of station :
45/55/75
Max.tablet diameter（mm） :
25/16/13
Rotation speed (r/min) :
75/75/75
Main.tablet diameter（KN） :
100/100/100
Description

Product overview:

Compression Automatic Rotary Tablet Press Machine Tablet Production Equipment

Model GZPK-45/55/75 Double Discharge High Speed Rotary Tablet Press is a product of British Manistee Company. After continuous technological innovation and improvement, it concentrates on the technical characteristics of the domestic automatic high speed rotary tablet press, featuring higher degree of automation, better operability, faster production speed, stronger stability performance and lower working noise. Its technology is located in the domestic leading level.

Technical parameters:

Model GZPK-45 GZPK-55 GZPK-75
Capacity (Tablets/h) 405000 495000 675000
No.of station 45 55 75
Max.tablet diameter(mm) 25 16 13
Rotation speed (r/min) 75 75 75
Main.tablet diameter(KN) 100 100 100
Pre-pressure(KN) 20 20 20
Main.filling depth(mm) 20 20 20
Dia.of.die(mm) 38.1 30.16 24
Length of punch(mm) 133.6 133.6 133.6
Total power(Kw) 7.5(frequency conversion11)
Overall weight(Kg) 4580
Overall diemensions(mm) 1520X1260X1850
Noise ≤75DB(A)

The machine may make technical improvements without prior notice, and the attached picture shows the options that may be offered.

Filling mechanism:

It can adjust the depth of the filling amount and control it by adding or reducing the material. For the lower CAM track can be based on the average filling depth, select the track average should be closest to the required filling value.

Double Discharge Automatic Tablet Press Machine Compression Tablet Production Equipment

Preloading mechanism:

Double Discharge Automatic Tablet Press Machine Compression Tablet Production Equipment

Main pressure mechanism:

Double Discharge Automatic Tablet Press Machine Compression Tablet Production Equipment

Release mechanism:

Double Discharge Automatic Tablet Press Machine Compression Tablet Production Equipment
