Specifications
Brand Name :
Canaan Kaixinlong
Model Number :
GZPK-45/55/75
Place of Origin :
Wenzhou China
MOQ :
1
Price :
GZPK-45/103000$ GZPK-55/106000$ GZPK-55/109000$
Model :
GZPK-45/GZPK-55/GZPK-75
Capacity （Tablets/h） :
40500/495000/675000
No.of station :
45/55/75
Max.tablet diameter（mm） :
25/16/13
Rotation speed (r/min) :
75/75/75
Main.tablet diameter（KN） :
100/100/100
Description

Product overview:

Automated High-Speed Rotary Tablet Press Tablet Production Equipment Tablet Press For Medical Purposes

Model GZPK-45/55/75 Double Discharge High Speed Rotary Tablet Press is a product of British Manistee Company. After continuous technological innovation and improvement, it concentrates on the technical characteristics of the domestic automatic high speed rotary tablet press, featuring higher degree of automation, better operability, faster production speed, stronger stability performance and lower working noise. Its technology is located in the domestic leading level.

Technical parameters:

Model GZPK-45 GZPK-55 GZPK-75
Capacity (Tablets/h) 405000 495000 675000
No.of station 45 55 75
Max.tablet diameter(mm) 25 16 13
Rotation speed (r/min) 75 75 75
Main.tablet diameter(KN) 100 100 100
Pre-pressure(KN) 20 20 20
Main.filling depth(mm) 20 20 20
Dia.of.die(mm) 38.1 30.16 24
Length of punch(mm) 133.6 133.6 133.6
Total power(Kw) 7.5(frequency conversion11)
Overall weight(Kg) 4580
Overall diemensions(mm) 1520X1260X1850
Noise ≤75DB(A)

The machine may make technical improvements without prior notice, and the attached picture shows the options that may be offered.

Material feeding method:

Hand feed Elevator feed (optional) Vacuum feeder (optional)
Automated High Speed Rotary Tablet Press device For Medical Purposes Automated High Speed Rotary Tablet Press device For Medical Purposes Automated High Speed Rotary Tablet Press device For Medical Purposes

1.Add the material to the hopper manually

2.High dust, high labor intensity
3.Suitable for smaller batch production
1.Material pipe with soft connection charging
2.The feeding process is closed, safe and hygienic
3.Suitable for mixing and feeding to solve the problem of stratification
1.Compact structure, airtight, no pollution, safety and health, low noise
2.Easy to install, easy to operate, fast delivery speed
3.Suitable for the height of 2.7m and above the floor workshop

Tablet polishing (optional):

1.Screen machine is a special polishing equipment for tablets, which can complete the dust removal work on the surface of various shapes of tablets.
2.Multilayer screen structure can effectively isolate tablets and dust.
3.The amplitude and production speed are continuously adjustable.
4.It is easy to disassemble and install, easy to use and clean.
5.Reliable performance, high efficiency, low noise
6.The entire production process is intuitive and visual.

Automated High Speed Rotary Tablet Press device For Medical Purposes

【 Tablet screen machine 】

Other auxiliaries:
Automated High Speed Rotary Tablet Press device For Medical Purposes
【 Metal Detector 】 (Optional)
1.Metals can be separated from materials
2.Integrated metal foreign object removal system, even if the metal is sealed in the product can be detected
3.Available in various calibers and sizes for all practical applications
4.Compact and easy to install

Automated High Speed Rotary Tablet Press device For Medical Purposes

【 Industrial vacuum cleaner 】
It is used for dust removal and collection in working turntable
