Specifications
Model Number :
HFSS-AP525
Description

1.Fire-rated access panel for wall or ceiling applications.
2. 1 mm galvanized steel frame.
3. Fire-rated rock wool and plasterboard interior.
4. White powder-coated finish or special colors available.
5. High durability and corrosion protection.
6. Installed with screws through pre-drilled frame holes.
7. Square lock operated by L-key.
8. Standard sizes: 30×30 cm, 40×40 cm, 50×50 cm, 60×60 cm.
9. All frames are welded for structural integrity.

10.Packaging: Each unit is individually boxed, then packed in a master carton.


Advantage:

Heavy-duty construction with 30-minute and 60-minute fire ratings, backed by official certification.


Regular size

Item Neck Size(mm) Opening Size W1×L1(mm) Overall Size W2×L2(mm)
HFSS-AP525 200x200 189.9x189.9 219.5x219.5
300x300 289.9x289.9 319.5x319.5
300x400 289.9x389.9 319.5x419.5
400x400 389.9x389.9 419.5x419.5
500x500 489.9x489.9 519.5x519.5
600x600 589.9x589.9 619.5x619.5
