Specifications
Description
Milk Factory Use Skimming Separator Fresh Cream Machine
Product Application
Juneng dairy separator features large capacity, excellent deoiling performance, high efficiency, and lower energy consumption. The advanced inlet and outlet design ensures gentle treatment throughout the separation process, preventing destructive air entry and maintaining product quality.
Milk products vary widely in composition, with even basic market milk containing different fat contents. The separator processes diverse dairy products including butter, cheese, quark, and yogurt.
Industrial Milk Cream Separator 5000-10000L/H 15KW 380V Industrial Milk Cream Separator 5000-10000L/H 15KW 380V Industrial Milk Cream Separator 5000-10000L/H 15KW 380V Industrial Milk Cream Separator 5000-10000L/H 15KW 380V
Main Features
  1. High rotating speed
  2. Operating stability
  3. Completely sealed inlet and outlet system
  4. Lower noise operation
  5. Perfect separation efficiency
Technical Specifications
Model Treatment capacity (L/H) Inlet Pressure (Mpa) Outlet pressure (Mpa) Motor power (Kw) Weight (Kg) Outline dimension (mm)
DHN360 2000-5000 0.05 0.1-0.35 7.5 1200 1530*1150*1500
DHN470 5000-10000 0.05 0.1-0.4 15 1600 1800*1200*1750
DHN550 10000-20000 0.05 0.1-0.4 22 2300 1950*1550*1960
DHN616 25000-35000 0.1 0.3 37 3000 2185*1728*2082
Industrial Milk Cream Separator 5000-10000L/H 15KW 380V Industrial Milk Cream Separator 5000-10000L/H 15KW 380V
Machine Components
Name: Drum
Brand: Juneng
Origin: China
The drum is the high-speed rotating component that performs material separation, serving as the heart of the separator. It receives power through precise taper fitting with the vertical shaft. Each numbered drum component must remain in its original configuration to maintain balance and safety.
Name: Shaft
Brand: Juneng
Origin: China
The vertical shaft transmits power through a speed step-up gear and high-speed rotating components. Its elastic bearing support allows precise height adjustment for optimal operation positioning between drum, centripetal pump, and water-inlet housing.
Industrial Milk Cream Separator 5000-10000L/H 15KW 380V Industrial Milk Cream Separator 5000-10000L/H 15KW 380V
Service Support
Pre-Sales Service
  • Inquiry and consulting support
  • Sample testing support
  • Factory viewing opportunities
Industrial Milk Cream Separator 5000-10000L/H 15KW 380V
After-Sales Service
  • Machine installation and operation training
  • Overseas engineer support for machinery service
Industrial Milk Cream Separator 5000-10000L/H 15KW 380V
Packaging & Delivery
Industrial Milk Cream Separator 5000-10000L/H 15KW 380V
Packaging Details
Size 123 (L) * 456 (W) * 789 (D)
Weight 1.2 T
Standard packaging uses wooden boxes (Size: L*W*H). European shipments include fumigated wooden boxes. For tight container fits, we offer PE film packaging or custom solutions per customer request.
