Automatic Control Mbr Mbbr Membrane Separation Containerized Sewage Water Treatment Plant
Automatic Control Mbr Mbbr Membrane Separation Containerized Sewage Water Treatment Plant
Automatic Control Mbr Mbbr Membrane Separation Containerized Sewage Water Treatment Plant
Automatic Control Mbr Mbbr Membrane Separation Containerized Sewage Water Treatment Plant
Automatic Control Mbr Mbbr Membrane Separation Containerized Sewage Water Treatment Plant
Automatic Control Mbr Mbbr Membrane Separation Containerized Sewage Water Treatment Plant
Automatic Control Mbr Mbbr Membrane Separation Containerized Sewage Water Treatment Plant
Automatic Control Mbr Mbbr Membrane Separation Containerized Sewage Water Treatment Plant
Automatic Control Mbr Mbbr Membrane Separation Containerized Sewage Water Treatment Plant
Automatic Control Mbr Mbbr Membrane Separation Containerized Sewage Water Treatment Plant
Automatic Control Mbr Mbbr Membrane Separation Containerized Sewage Water Treatment Plant
Automatic Control Mbr Mbbr Membrane Separation Containerized Sewage Water Treatment Plant
Specifications
Condition :
New
Applicable Industries :
Hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction works , Energy & Mining, Food & Beverage Shops, Other
Showroom Location :
None
Video outgoing-inspection :
Provided
Machinery Test Report :
Provided
Marketing Type :
Hot Product 2024
Warranty of core components :
1 Year
Core Components :
Gearbox, Pressure vessel, Pump, Gear, Bearing, Engine, Motor, PLC
Place of Origin :
Shandong, China
Brand Name :
Juchuan
Size :
3.1*1.5*2.4m
Power :
1.28
Warranty :
1 Year
Productivity :
50m3/d
Weight (KG) :
8000 kg
Product name :
MBR membrane bioreactor
Type :
Sewage Treatment Plant
Function :
Removing COD BOD NH-N
Processing :
Membrane Separation Technology
Technology :
Membrane Separation + Biological Treatment
Control mode :
Automatic control
Color :
Customized Color
Capacity :
20-200m3/d
Material :
anti-corrosion carbon steel
Packing :
Wooden Case Paking
Port :
Qingdao Port
Price :
$4,000.00 - $15,000.00/sets
Description
Product Overview

MBR Membrane BioReactor

The membrane bioreactor reactor（MBR）is suitable for domestic sewage treatment. After treatment, the content of suspended matter can be reduced to the minimum, the water is clear and transparent, and can also remove some macromolecular organic matter, so that it can be directly used as recycled water for greening, flushing, etc. MBR is mainly composed of bioreactor and membrane components, organic matter in wastewater after the bioreactor microbial adsorption degradation process, make the water quality purification, and membrane components are mainly activated sludge and macromolecular organic matter and bacteria trapped in the reactor, by controlling the sludge back to keep the reactor always have high sludge concentration, membrane filtered water meet the water quality standards.

Products Description
Automatic Control Mbr Mbbr Membrane Separation Containerized Sewage Water Treatment Plant
(1) Simple technical process, no need for the second sedimentation tank. (2) Less land occupation, and saving on investment. (3) Consistent water quality of discharge water quality. (4) Little residual sludge and low cost on treatment. (5) Full automation , simple operation, convenient maintenance.
Project
Inlet water (mg/L)
Outlet water (mg/L)
COD
<400
20
BOD5
<300
5
SS
<300
2.0
NH4-N
<20
2.0
PH
6.0-9.0
6.0-9.0
Note: The inlet and outlet water quality can be adjusted according to the water quality data provided by customer.
Product Performance

Compact equipment, less footprint.

The sludge concentration in the bioreactor is increased by 2~5 times, so the volume load can be greatly increased, and the secondary sedimentation tank and filter equipment are replaced by membrane components, the footprint of the membrane bioreactor can be greatly reduced compared with the conventional biological treatment process.

Quality and stable effluent water.

Due to the efficient separation of the membrane, the separation effect is much better than the traditional sedimentation tank, the treated water is extremely clear, the suspended matter and turbidity are close to zero, bacteria and viruses are greatly removed, the effluent water quality is better than the standard of miscellaneous water, which can be directly reused as non-drinking municipal miscellaneous water.
At the same time, membrane separation completely intercepts microorganisms in the bioreactor, allowing the system to maintain a higher concentration of microorganisms, It not only improves the overall removal efficiency of pollutants in the reaction device, but also ensures good effluent quality. At the same time the reactor for water load (water quality and quantity) of various changes has good adaptability, impact load, can obtain stable quality effluent water quality.

The sludge age is long, and the surplus sludge is less.

The process can operate under high volume load and low sludge load, and the residual sludge yield is low (theoretically, zero sludge discharge can be realized), which reduces the cost of sludge treatment.

Effectively removing ammonia nitrogen and refractory organic matter.

The microorganisms are completely blocked in the bioreactor, which is conducive to the interception and growth of slowly proliferating microorganisms such as nitrifying bacteria, the systematic nitrification efficiency can be improved. At the same time, it can increase the hydraulic residence time of some refractory organic matter in the system, which is conducive to the improvement of the degradation efficiency of refractory organic matter.

Convenient operation and management, easy to achieve automatic control.

This process realizes the complete separation of hydraulic retention time (HRT) and sludge age (SRT), and the operation control is more flexible and stable. It is a new technology that can be easily equipped in sewage treatment and can realize microcomputer automatic control, thus making operation and management more convenient.

Easy to transform from traditional techniques.

The process can be used as the deep treatment unit of the traditional sewage treatment process, and has a broad application prospect in the field of the effluent deep treatment of the urban secondary sewage treatment plant (so as to realize a large amount of urban sewage reuse) and other fields.

Low power consumption.

The suction pressure required by the hollow silk film is only about -0. 1~ -0. 4 kg /cm2, and the power consumption is very low. In recent years, due to the improvement of membrane production process and the application of new materials, effectively reducing the phenomenon of membrane pollution blockage and the workload of cleaning, and prolonging the life of membrane components, with the life of up to 3~5 years.
Recommend Products
Automatic Control Mbr Mbbr Membrane Separation Containerized Sewage Water Treatment Plant
Automatic Control Mbr Mbbr Membrane Separation Containerized Sewage Water Treatment Plant
Automatic Control Mbr Mbbr Membrane Separation Containerized Sewage Water Treatment Plant
Product Paramenters
Model
Treatment of water quantity (m3/d)
Dimensions (m)
Weight (t)
Power (kW)
JCMBR-20
20
3.1*1.5*2.4
8.24
1.28
JCMBR-40
40
2.8*2.4*2.4
13.89
1.68
JCMBR-50
50
3.6*2.4*2.4
19.86
2.38
JCMBR-70
70
5.4*2.4*2.4
30.78
3.37
JCMBR-100
100
4.8*3.5*2.4
41.72
4.55
JCMBR-150
150
7.1*3.5*2.4
62.82
6.25
JCMBR-200
200
7.2*4.6*2.4
84.45
8.6
Note: Unconventional size can be made according to the water quality and water quantity provided by customer.
Applications
Hotels, restaurants, nursing homes, hospitals; Residential areas, villages and market towns; Station, airport, seaport, ships; Plants, mines, troops, tourist spots, scenic spots; Various industrial organic wastewater similar to domestic sewage.
Product process principle
Automatic Control Mbr Mbbr Membrane Separation Containerized Sewage Water Treatment Plant
Product structure principle
MBR is a new type of high efficiency sewage treatment process that combines high efficiency membrane separation technology with traditional activated sludge method. It uses MBR sheet membrane components with unique structures in the aeration tank. After aerobic aeration and biological treatment, the water is extracted by the pump through the filter membrane. It uses the membrane separation equipment to intercept the activated sludge and macromolecular organic substances in the biochemical reaction tank, and save the secondary sedimentation tank. The concentration of activated sludge is therefore greatly increased, and the hydraulic residence time (HRT) and sludge age (SRT) can be controlled respectively, while the refractory substances constantly react and degrade in the reactor.
Why Choose Us
Automatic Control Mbr Mbbr Membrane Separation Containerized Sewage Water Treatment Plant
Order Instructions
1. If you don’t know which equipment model to choose, please contact us and we will consult you with some technical performance requirements to help you choose the appropriate model.
2. Select the technical performance and process requirements, and indicate the models and specifications.
3. If there are no requirements for equipment material and anti-corrosion performance, it will use carbon steel for ordinary anti-corrosion.
4. The grille of this complete set of equipment is artificial grille, and the automatic mechanical grille should be ordered separately.
5. Infeed pump, external pipes, valves, etc. shall be ordered separately. 6. The equipment foundation and embedded parts shall be provided by customer.
