Specifications
Brand Name :
JSTARY
Model Number :
JX-B24230
Certification :
UN38.3 MSDS CE
Place of Origin :
CHINA
MOQ :
5Pcs
Payment Terms :
L/C,D/A,D/P,T/T,Western Union,MoneyGram
Supply Ability :
1,000 items per week
Delivery Time :
5 - 7 working days
Packaging Details :
Ship safely in wooden crates or cardboard boxes.
Description





High-Capacity 24V 230Ah Battery for Sweepers-Reliable Power Output





As a battery adopting the lithium iron phosphate (LiFePO₄) chemical system, it far surpasses traditional lead-acid batteries in terms of safety and stability. The thermal runaway temperature of lithium iron phosphate materials is as high as 800°C or more. When used in crowded places such as shopping malls and hospitals in Europe and America, even in case of accidents like collisions or punctures, it can avoid the risk of fire or explosion. This characteristic enables it to pass strict safety tests in the European Union, making it the designated choice for scenarios with extremely high safety requirements. Meanwhile, this material has excellent low-temperature performance. In the outdoor environment of minus 10°C in Nordic winters, the capacity retention rate can still reach more than 85%, ensuring the normal operation of the floor sweeper in cold weather. In contrast, the capacity of traditional batteries may drop by more than 50% under the same conditions.




High-Capacity 24V 230Ah Battery for Sweepers-Reliable Power Output





24V 230AH Sweeper Battery
Parameter Details
Nominal Voltage 25.6V
Nominal Capacity 230Ah
Total Energy 5.88KWh
Max Charge Voltage 29.2V (prevents overcharging)
Discharge Cut-off 20V (recharge to avoid damage)
Standard Charge Current 30A, ~8-hour full charge
Max Charge 115A (continuous)
Max Discharge 230A
Peak Discharge Current 600A (5s)
Cycle Life >4000 cycles @80% DOD
Charge Temp 0°C–60°C
Discharge Temp -20°C–65°C
Dimensions 478×266×240mm (Customizable)
Weight 90KG
IP Rating IP65 (dust/water resistant)
BMS Protection Over Charge, Over Discharge, Over Current, Short Circut, High temperature alarm





Stable Voltage Output: 24V nominal voltage (25.6V when fully charged). Thanks to lithium iron phosphate's superior electrochemical properties, voltage fluctuation during discharge is strictly controlled within ±0.5V. This ensures uniform brush rotation on marble floors in European and American supermarkets, eliminating voltage-induced cleaning marks for a mirror-like finish. For hotel carpets, stable voltage maintains strong vacuum suction to deep-clean fibers, removing hidden dust and mites — meeting strict EU/US cleaning standards.




High-Capacity 24V 230Ah Battery for Sweepers-Reliable Power Output





Large Capacity & Long Endurance: 230AH capacity stores 5888Wh, with 30% more energy than same-volume lead-acid batteries due to lithium iron phosphate's high density. In German logistics warehouses, sweepers with this battery run 6-8 hours per charge, covering 10,000㎡ (2,000㎡ more than traditional batteries). Ideal for large spaces like malls, airports, and logistics hubs, it reduces charging interruptions and boosts cleaning efficiency.




High-Capacity 24V 230Ah Battery for Sweepers-Reliable Power Output




Powerful discharge performance: 230A continuous current, 320A peak. Lithium iron phosphate's high-rate discharge capability delivers instant power for high-demand tasks — like tackling floor tile gaps or stubborn oil stains. In Italian restaurant kitchens, for instance, the brush head speeds up 30% instantly to blast caked grease (when paired with cleaners), while traditional batteries lag due to weak discharge, slowing cleaning drastically.




High-Capacity 24V 230Ah Battery for Sweepers-Reliable Power Output
