API 5CT Double Valve Casing Float Shoe 2KG for Well Drilling
API 5CT Double Valve Casing Float Shoe 2KG for Well Drilling
API 5CT Double Valve Casing Float Shoe 2KG for Well Drilling
API 5CT Double Valve Casing Float Shoe 2KG for Well Drilling
API 5CT Double Valve Casing Float Shoe 2KG for Well Drilling
API 5CT Double Valve Casing Float Shoe 2KG for Well Drilling
API 5CT Double Valve Casing Float Shoe 2KG for Well Drilling
API 5CT Double Valve Casing Float Shoe 2KG for Well Drilling
API 5CT Double Valve Casing Float Shoe 2KG for Well Drilling
API 5CT Double Valve Casing Float Shoe 2KG for Well Drilling
API 5CT Double Valve Casing Float Shoe 2KG for Well Drilling
API 5CT Double Valve Casing Float Shoe 2KG for Well Drilling
Specifications
Place of Origin :
China
Certification :
ISO API
MOQ :
1
Weight :
2 KG
Core Components :
Valve
Valve type :
single valve & double valve
Machine Type :
Drilling Tool
Processing Type :
Forging
Size :
5 1/2", 7", 9 5/8", 13 3/8"
Bore O.D. :
6", 7 5/8", 10 5/8", 14 3/8"
Bore I.D. :
4 3/4", 6 1/4", 8 5/8", 12 3/8"
Min Bore :
2", 2 3/8"
Thread Type :
5 1/2" LCSG, 7" LCSG, 9 5/8" LCSG, 13 3/8" LCSG
Pressure Rating :
4351, 3626 lb/in2
Standard :
API 5 CT
Color :
Customized
Use :
Well Drilling
Applicable Industries :
Energy & Mining
Description
Factory Cheap Price Differential Fill up Double Valve Casing Float Shoe
Float equipment serves as the backbone of casing equipment used during primary cementing operations. Float equipment guides the casing to total depth and prevents contaminated mud from entering the casing. Also, it provides a landing point for casing wiper plugs, reinforces the lower end of the casing string, and ensures great accuracy of cement slurry displacement.
API 5CT Double Valve Casing Float Shoe 2KG for Well Drilling API 5CT Double Valve Casing Float Shoe 2KG for Well Drilling API 5CT Double Valve Casing Float Shoe 2KG for Well Drilling API 5CT Double Valve Casing Float Shoe 2KG for Well Drilling API 5CT Double Valve Casing Float Shoe 2KG for Well Drilling
Specifications
Name Size(in) Bore O.D.(in) Bore I.D.(in) Min Bore Parameter(in) Thread Type lb(in2)
Float Collar 5 1/2" 6" 4 3/4" 2" 5 1/2" LCSG 4351
7" 7 5/8" 6 1/4" 2 3/8" 7" LCSG 3626
9 5/8" 10 5/8" 8 5/8" 2 3/8" 9 5/8" LCSG 3626
13 3/8" 14 3/8" 12 3/8" 2 3/8" 13 3/8" LCSG 3626
Float Shoe 5 1/2" 6" 4 3/4" 2" 5 1/2" LCSG 4351
7" 7 5/8" 6 1/4" 2 3/8" 7" LCSG 3626
9 5/8" 10 5/8" 8 5/8" 2 3/8" 9 5/8" LCSG 3626
13 3/8" 14 3/8" 12 3/8" 2 3/8" 13 3/8" LCSG 3626
Company Profile
API 5CT Double Valve Casing Float Shoe 2KG for Well Drilling
Our Factory
API 5CT Double Valve Casing Float Shoe 2KG for Well Drilling
Device Image
API 5CT Double Valve Casing Float Shoe 2KG for Well Drilling
Exhibition
API 5CT Double Valve Casing Float Shoe 2KG for Well Drilling
Certifications
API 5CT Double Valve Casing Float Shoe 2KG for Well Drilling
Product Packaging
API 5CT Double Valve Casing Float Shoe 2KG for Well Drilling
Frequently Asked Questions
API 5CT Double Valve Casing Float Shoe 2KG for Well Drilling
Q1: When can I get the price?
A: We usually quote within 24 hours after we get your inquiry. If you are very urgent to get the price, please tell us in your email so that we will regard your inquiry as priority.
Q2: Could I have prices of your products?
A: Welcome. Please feel free to send us an email here. You will get our reply in 24 hours.
Q3: Can I get a lower price if I order large quantities?
A: Yes, cheaper prices are available for larger quantity orders.
Q4: Do you inspect the finished products?
A: Yes, each step of production and finished products will be inspected by our QC department before shipping.
Q5: What about the lead time for the mass production?
A: The lead time depends on the order quantity and the season you place the order.
