Specifications
Place of Origin :
Jiangsu, China
Brand Name :
SWS
MOQ :
1
Weight :
10 KG
Core Components :
valve
Valve type :
single valve & double valve
Machine Type :
Drilling Tool
Processing Type :
Forging
Size :
5 1/2", 7", 9 5/8", 13 3/8"
Bore O.D. :
6", 7 5/8", 10 5/8", 14 3/8"
Bore I.D. :
4 3/4", 6 1/4", 8 5/8", 12 3/8"
Min Bore :
2", 2 3/8"
Thread Type :
5 1/2" LCSG, 7" LCSG, 9 5/8" LCSG, 13 3/8" LCSG
Pressure Rating :
4351, 3626 lb/in2
Description
Self-Locking Cementing Float Shoe
Float equipment serves as the backbone of casing equipment used during primary cementing operations. Float equipment guides the casing to total depth and prevents contaminated mud from entering the casing. Also, it provides a landing point for casing wiper plugs, reinforces the lower end of the casing string, and ensures great accuracy of cement slurry displacement.
API Self-Locking Cementing Float Shoe 10 KG for Well Drilling
Specifications
Name Size(in) Bore O.D.(in) Bore I.D.(in) Min Bore Parameter(in) Thread Type lb(in2)
Float Collar 5 1/2" 6" 4 3/4" 2" 5 1/2" LCSG 4351
7" 7 5/8" 6 1/4" 2 3/8" 7" LCSG 3626
9 5/8" 10 5/8" 8 5/8" 2 3/8" 9 5/8" LCSG 3626
13 3/8" 14 3/8" 12 3/8" 2 3/8" 13 3/8" LCSG 3626
Float Shoe 5 1/2" 6" 4 3/4" 2" 5 1/2" LCSG 4351
7" 7 5/8" 6 1/4" 2 3/8" 7" LCSG 3626
9 5/8" 10 5/8" 8 5/8" 2 3/8" 9 5/8" LCSG 3626
13 3/8" 14 3/8" 12 3/8" 2 3/8" 13 3/8" LCSG 3626
