HOWO 6X4 Heavy Cargo Truck 400HP 20tons Lorry Fence Cargo Truck
HOWO 6X4 Heavy Cargo Truck 400HP 20tons Lorry Fence Cargo Truck
HOWO 6X4 Heavy Cargo Truck 400HP 20tons Lorry Fence Cargo Truck
HOWO 6X4 Heavy Cargo Truck 400HP 20tons Lorry Fence Cargo Truck
HOWO 6X4 Heavy Cargo Truck 400HP 20tons Lorry Fence Cargo Truck
HOWO 6X4 Heavy Cargo Truck 400HP 20tons Lorry Fence Cargo Truck
HOWO 6X4 Heavy Cargo Truck 400HP 20tons Lorry Fence Cargo Truck
HOWO 6X4 Heavy Cargo Truck 400HP 20tons Lorry Fence Cargo Truck
HOWO 6X4 Heavy Cargo Truck 400HP 20tons Lorry Fence Cargo Truck
HOWO 6X4 Heavy Cargo Truck 400HP 20tons Lorry Fence Cargo Truck
Specifications
Brand Name :
SINOTRUK
Model Number :
ZZ1317N4661W
Certification :
CCC
Place of Origin :
JINAN, CHINA
MOQ :
1
Price :
USD41000 for one unit
Supply Ability :
1000 sets for one month
Delivery Time :
5 working days
Packaging Details :
nude packing
Box Dimenssion :
7800*2500*3000
Oil Tank :
400L
Transmission :
Hw19710
Horsepower :
351-450hp
Wheelbase :
4300mm
Production Capacity :
500units
Description

Cargo Truck:Cargo Truck is a form of vehicle used to transport goods and commodities,
which is divided into box trucks, flat trucks, fence trucks, warehouse trucks, etc.

The standard for warehouse grate type transport vehicles is called warehouse grate type specialized

transport vehicles. In terms of exterior design, the carriage strives for beautiful appearance, reasonable

internal structure, and advanced technology. It uses high-quality steel as the skeleton and is strictly

welded according to industry standards. The box board is pressed into a corrugated shape by fixtures,

with high strength.

Model ZZ1257N4341W
Cabin HW76, with two seats and one bed, 2-arm windscreen wiper system with three speeds, damped adjustable driver's seat, with heating
and ventilating system, exterior sun visor, safety belts, adjustable steering wheel, air horn, air conditioner, with transverse
stabilizer, with 4-point support fully floating suspension + shock absorber + air roof spoiler

Engine		 Model WD615.47
Horse Power (Hp/rpm) 400/2200
Max.Toruqe(Nm/rpm) 1820/1100-1500
Displacement (L) 9.726
Type DIESEL, EURO II emission, 6-cylinder in-line with water cooling, turbo-charging and intercooling, 4-stroke common rail electronic
controlled diesel engine
Clutch Φ430 Diaphragm spring clutch, hydraulic operating with air assistance
Transmission HW19712, 12 speeds forward and 2 speeds reverse.
Front Axle HF9, Steering with double T-cross section beam, Rated loading capacity: 9,000kgs.
Driving Axle HC16, Pressed axle housing, central reduction with hub reduction and with differential locks between wheels and axles(Ratio: 4.42,
4.8)
Suspension Front suspension: hydraulic telescopic double-action shock absorbers and stabilizer; Rear suspension: leaf semi-elliptic springs,
bogie spring and stabilizer
Steering System ZF power steering, model ZF8118, hydraulic steering with power assistance
Brake System Service brake: Dual circuit compressed air brake; Parking brake (emergency brake): Spring energy, compressed air operating;
Auxiliary brake: Engine exhaust brake
Electrics Single wire, 24 V, negative grounded; Alternator: 1540W; Start Motor:7.5kW;Battery:2*12V/165Ah
Tire 12.00R20
Fuel Tank(Gas Tank) Capacity (L) 400L Diesel Tank
Dead Weight (kg) 12530
Gross Vehicle Weight (kg) 33000
Gross Combination Weight (kg) 80000
Overall Dimension(L*W*H)(mm) 8145×2560×3450
Wheelbase(mm) 5000+1350
Front/Rear Overhang( mm) 1500/725
Wheel Track(Front/Rear)(mm) 2022/1850
Min. Ground Clearance(mm) 314
Approach/Departure Angle( °) 16/70
Max. Speed (km/h) 92
Max. Gradebility (%) ≥40
Bucket Size 7500*2300*1800mm


HOWO 6X4 Heavy Cargo Truck 400HP 20tons Lorry Fence Cargo TruckHOWO 6X4 Heavy Cargo Truck 400HP 20tons Lorry Fence Cargo TruckHOWO 6X4 Heavy Cargo Truck 400HP 20tons Lorry Fence Cargo TruckHOWO 6X4 Heavy Cargo Truck 400HP 20tons Lorry Fence Cargo TruckHOWO 6X4 Heavy Cargo Truck 400HP 20tons Lorry Fence Cargo Truck
A truck equipped with cage or fence structure carriages, with grids installed at a certain distance inside the
cage or fence for transporting items.
Classification of transport vehicles: livestock and poultry transport vehicles, bulk beverage transport vehicles,
beekeeping vehicles, and bucket garbage transport vehicles.


HOWO 6X4 Heavy Cargo Truck 400HP 20tons Lorry Fence Cargo Truck
HOWO 6X4 Heavy Cargo Truck 400HP 20tons Lorry Fence Cargo Truck
