23AWG SFTP CAT6 Cable High Speed Network Cable With Blue PVC Jacket 1000ft
23AWG SFTP CAT6 Cable High Speed Network Cable With Blue PVC Jacket 1000ft
23AWG SFTP CAT6 Cable High Speed Network Cable With Blue PVC Jacket 1000ft
23AWG SFTP CAT6 Cable High Speed Network Cable With Blue PVC Jacket 1000ft
23AWG SFTP CAT6 Cable High Speed Network Cable With Blue PVC Jacket 1000ft
23AWG SFTP CAT6 Cable High Speed Network Cable With Blue PVC Jacket 1000ft
23AWG SFTP CAT6 Cable High Speed Network Cable With Blue PVC Jacket 1000ft
23AWG SFTP CAT6 Cable High Speed Network Cable With Blue PVC Jacket 1000ft
Specifications
Brand Name :
ITI-LINK
Model Number :
ITI-CT6SF-018
Certification :
UL, ETL, CSA, RCM, TUV, CPR, CE, RoHS
Place of Origin :
SHENZHEN
MOQ :
1000pcs
Price :
$50-$100
Payment Terms :
T/T
Supply Ability :
2000pcs/day
Delivery Time :
15-45 Days
Packaging Details :
Color Box+Packing Box 36*36*21cm
Cable Type :
CAT6
Maximum Frequency :
250MHz
Shielding Type :
SFTP
Color :
Red
Maximum Transmission Distance :
100 Meters
Conductor Size :
23AWG
Jacket Material :
PVC
Conductor Material :
Copper
Description

Cat6 SFTP 23AWG High Speed Network Cable With Blue PVC Jacket 1000ft

Product Description:

  1. The ITI-CT6SF-018 CAT6 SFTP Cable from ITI-LINK is a 305-meter, 23AWG network cable with a bright red PVC jacket, designed to meet the most demanding performance requirements.
  2. It provides fast and reliable data transmission, ensuring uninterrupted connectivity for home, office, and industrial users.
  3. Equipped with SFTP shielding, this CAT6 cable offers exceptional protection against electromagnetic interference, making it suitable for noisy environments like internet cafés or manufacturing plants.
  4. Its 305-meter transmission distance allows easy connection of devices across long ranges without losing speed or signal quality; supporting up to 10Gbps data rate and 250MHz frequency, this SFTP CAT6 cable excels in high-bandwidth tasks such as 4K/8K streaming, large data transfers, and online gaming.
  5. Made of premium materials, it delivers long-term durability (the red jacket resists environmental damage and wear, while the 23AWG construction ensures optimal signal integrity); the flexible PVC material simplifies installation, and the plug-and-play design enables quick network setup; available for bulk sale, wholesale, and OEM production, this CAT6 SFTP cable is a versatile solution for all networking needs.

Technical Parameters:

Product Description:

Cat6 SFTP 23AWG High Speed Network Cable With Blue PVC Jacket 1000ft
Rev.: A ECN Description:
Construction Item Description Electrical Property


Conductor


Material

Bare Solid Copper(elongation:

19-24%)

 Conductor Resistance at 20°C ≤ 9.5 Ω / 100m
OD 23 AWG Resistance unbalance within a pair ≤ 2%






Insulation

 Material


HDPE

 Insulation Resistance at 20°C after 2min of electrification under a DC voltage between 100 & 500V


>1500 MΩ / 100m
OD 1.14 ±0.05 mm Mutual capacitance 5600 pF / 100m MAX
Average THK 0.24 mm Capacitance unbalance pair to ground at 800Hz or 1 kHz ≤ 160 pF / 100m



Color

 1p: white + 2 blue stripes & blue Characteristic impedance at 100MHz 100 ± 15 Ω
2p: white + 2 orange stripes & orange

Dielectric Strength Test Voltage (cd/cd,cd/screen): 1.00KV DC or

0.7 KV AC for 1 min


No breakdown
3p: white + 2 green stripes & green Mechanical Property
4p: white + 2 brown stripes & brown



insulation

 elongation before aging ≥ 300%



Pair Twist



Lay & Direction

 1p: S=19.0 mm (27%) tensile strength before aging ≥12 MPa
2p: S=23.5 mm (35%) elongation after aging ≥ 150 %
3p: S=21.5 mm (31%) tensile strength after aging ≥10.5 MPa
4p: S=27.0 mm (40%)



jacket

 elongation before aging ≥ 150 %
OD / tensile strength before aging ≥ 13.5 MPa


Inner Assemble

 Lay S=90 ± 5 mm elongation after aging ≥ 125 %
Direction according to the drawing tensile strength after aging ≥ 12.5 MPa
Filler cross member 5.0X5.0X0.5mmT Packing
OD / NA NA
Filler Ripcord 300D

Drain Wire Tinned Copper





Shield

 Shield Shield
Construction /
Material Polyester/Aluminium (PET/ALU)
Coverage ≥ 115%





Jacket

 Material PVC, 50P, -20~75℃
Hardness 81± 3
OD 7.2 ± 0.2
Average THK 0.55 ~ 0.60


Color

Blue
Marking Color

according to the customer's

requirements
Marking

according to the customer's

requirements



Applications:

  1. Home Networks: Ideal for large families with multiple devices, the SFTP CAT6 cable supports 4K/8K streaming, online gaming, and smooth browsing without buffering, providing a seamless experience.
  2. Small & Medium Businesses: Connects computers, printers, and servers, handling daily data transfers with 10Gbps speed to improve office work efficiency.
  3. Data Centers: Links servers and storage devices, using high bandwidth and low latency to ensure fast, reliable data transfer for data-intensive operations.
  4. Commercial Buildings: Covers long distances (up to 305m) to connect multiple floors/areas, ensuring smooth network coverage across the building for businesses.
  5. Wholesale & Bulk Projects: Suitable for schools, campuses, and large-scale projects, available for bulk purchase and OEM production to meet unified network setup needs.
