Toyota 2L 2LT 2LTE MLS Head Gasket 11115-54084-F0 - Grade F Thickest 1.65mm Multi-Layer Steel Construction
Toyota 2L 2LT 2LTE MLS Head Gasket 11115-54084-F0 - Grade F Thickest 1.65mm Multi-Layer Steel Construction
Toyota 2L 2LT 2LTE MLS Head Gasket 11115-54084-F0 - Grade F Thickest 1.65mm Multi-Layer Steel Construction
Toyota 2L 2LT 2LTE MLS Head Gasket 11115-54084-F0 - Grade F Thickest 1.65mm Multi-Layer Steel Construction
Specifications
Certification :
ISO/TS16949
Price :
Negotiable
Compressed Thickness :
1.60–1.70 mm (0.0630-0.0669 in)
Compression Ratio :
2L (NA): 22.3:1; 2L-T (Turbo): 20:1; 2LTE: 21.2:1
MOQ :
10 pcs
Packaging Details :
Neutral Package or as customers’ request
Max Power :
86-91 PS (63-67 kW, 85-90 hp) at 4,000 rpm
Supply Ability :
10000 pcs/month
Head Bolt Count :
18 (two lengths: 107mm Type A, 127mm Type B)
Bore × Stroke :
92.0 mm × 92.0 mm
Delivery Time :
5-8 Work Days
Engine Displacement :
2.4 L (2,446 cc / 149.3 cu in)
Payment Terms :
T/T,Western Union
Brand Name :
YIMI
Place of Origin :
China
Model Number :
Toyota Crown Hiace Hilux 2L 2LT 2LTE
Gasket Type :
Multi-Layer Steel (MLS)
Max Torque :
188 N·m (138.6 ft-lb, 19.2 kg·m) at 2,200 rpm
Description
Cylinder Head Gasket 11115‑54084‑F0 For Toyota Crown Hiace Hilux 2L 2LT 2LTE — MLS Head Gasket Grade F Thickest
Product Overview

The Cylinder Head Gasket with OEM number 11115‑54084‑F0 (Type F – thickest Grade) is a verified direct-fit replacement for second-generation Toyota 2L, 2LT, and 2LTE 2.4L turbo-diesel engines (post-August 1988). This MLS (Multi-Layer Steel) head gasket provides superior sealing performance for high-compression diesel applications.

Key Specifications
Part Number 11115‑54084‑F0
Gasket Type Multi-Layer Steel (MLS)
Thickness 1.65mm (Grade F - Thickest)
Engine Compatibility 2L-II, 2LT-II, 2LTE 2.4L Turbo-Diesel
Head Bolt Type TTY (Torque-to-Yield) - 18 bolts
Important Fitment Notes: Compatible with second-generation 2L-II/2LT-II/2LTE engines with shim-over-bucket design (post-1990). Not compatible with first-generation 2L/2LT engines (pre-1988). Cylinder head bolts are torque-to-yield and MUST be replaced during installation.
Vehicle Applications
  • Toyota Crown (JZS133, JZS135) - 1991-1995
  • Toyota Hiace (LH51, LH61, LH71) - 1989-1995
  • Toyota Hilux/4Runner (LN8#, LN9#, LN10# series) - 1988-1998
  • Toyota Land Cruiser Prado (LJ71, LJ78) - 1990-1996
  • Toyota Regius Ace (LH120G) - 1990-1995
Features & Benefits
MLS Construction - Superior sealing under turbocharged cylinder pressures up to 188 N·m torque output
Grade F Thickness - Accommodates maximum piston protrusion with 1.65mm compressed thickness
Precision Embossed Beads - Leak-proof seal with consistent clamping pressure across entire surface
Elastomer Coating - Enhanced surface conformability for micro-imperfection accommodation
OE Specification - Direct bolt-on replacement with exact bolt pattern and coolant passages
Quality Certified - IATF 16949 and ISO 9001:2015 certified manufacturing
Toyota 2L 2LT 2LTE MLS Head Gasket 11115-54084-F0 - Grade F Thickest 1.65mm Multi-Layer Steel Construction
Common Failure Symptoms
  • Coolant loss with no visible external leak
  • White/gray smoke from exhaust
  • Milky oil emulsion (coolant contamination)
  • Oil floating in coolant reservoir
  • Persistent overheating after cooling system service
  • Loss of power under load
  • Rough idle or engine misfire
  • Exhaust bubbles in radiator
Installation Requirements
  • Identify correct engine generation (2L-II/2LT-II/2LTE only)
  • Inspect cylinder head for cracks or warpage
  • Measure piston protrusion to confirm Grade F requirement
  • Replace all 18 cylinder head bolts (TTY - single use only)
  • Follow Toyota torque sequence: 78 N·m + 90° + 90°
  • Install gasket dry - no sealants required
Ready to Order?

Available for wholesale pricing, single unit samples, and bulk orders with custom export packaging. Provide your vehicle details and quantity requirements for accurate fitment verification.
