ITX-Y3399 Intelligent Industrial Computing Motherboard

Overview

The ITX-Y3399 Intelligent Industrial Computing Motherboard delivers flagship performance in a standard Mini-ITX form factor (170mm × 170mm), offering seamless compatibility with X86 motherboard mounting structures for easy integration into existing industrial chassis. Powered by the Rockchip RK3399 hexa-core processor (dual Cortex-A72 @ 1.8GHz + quad Cortex-A53 @ 1.4GHz), this board combines exceptional computing power with industrial-grade reliability. What sets the ITX-Y3399 apart is its M.2 PCIe NVMe SSD support for ultra-fast storage, 2× isolated DB-9 serial ports for reliable industrial communication, dual Gigabit Ethernet with PoE, Wi-Fi 6, and 4G/5G module expansion via PCIe. The board also features HDMI input for video capture, 5× display interfaces (HDMI 2.0a 4K, LVDS, eDP, MIPI-DSI, and VGA), 8Ω 6W dual amplifier output, and wide-temperature operation from -20°C to 70°C. With support for Android 7.1/8.1/9.0 and Linux (Buildroot/Debian 9/Ubuntu 18.04), plus optional Megvii face recognition authorization, the ITX-Y3399 is the ultimate platform for industrial all-in-one computers, touch一体机, and high-performance embedded systems.

Key Advantages

• M.2 PCIe NVMe SSD Support: Onboard M.2 socket supports NVMe 2242/2260/2280 SSDs — delivering blazing-fast read/write speeds, low latency, and excellent power efficiency for data-intensive industrial applications.

• Isolated DB-9 Serial Ports: 2× DB-9 serial ports with signal and power isolation — protect against ground loops, voltage spikes, and electrical noise, ensuring reliable communication in harsh industrial environments.

• Dual Gigabit Ethernet with PoE: 2× 10/100/1000M Ethernet ports with 4-pin PoE PD header — enable network redundancy, fast data transfer, and power over Ethernet for simplified cabling.

• Wi-Fi 6 + Bluetooth 5.0: Built-in Wi-Fi 6 (802.11 a/b/g/n/ac/ax) with dual-band 2.4GHz/5GHz support and Bluetooth 5.0 — next-gen wireless connectivity for fast, reliable communication in crowded environments.

• 5× Display Interfaces with HDMI Input: HDMI 2.0a (4K), LVDS (1080P), eDP (1080P), MIPI-DSI (1920×1200), and VGA (1080P) — plus HDMI 2.0 input for video capture. Unmatched display flexibility for multi-screen industrial applications.

• Standard Mini-ITX Form Factor: 170mm × 170mm board with standard mounting holes — compatible with X86 chassis and industrial enclosures, simplifying integration and reducing custom design costs.

• PCIe 4G/5G Expansion: Industry-standard PCIe slot for 4G/5G modules with Micro-SIM socket — enable cellular connectivity for remote monitoring, fleet management, and IoT applications.

• Wide-Temperature Reliability: -20°C to 70°C operating temperature range — ensures stable performance in outdoor installations, cold storage, and high-temperature industrial environments.

Why Choose This Board?

• Enterprise-Grade Storage Performance: M.2 PCIe NVMe support delivers dramatically faster read/write speeds than eMMC or SATA — ideal for data logging, video recording, and applications requiring rapid boot times and large dataset access.

• Industrial Communication You Can Rely On: Isolated DB-9 serial ports protect against electrical interference and ground loops — ensuring reliable communication with PLCs, sensors, and industrial equipment in electrically noisy environments where standard serial ports would fail.

• Standard Mini-ITX — Drop-In Replacement: 170mm × 170mm form factor with standard mounting holes means the ITX-Y3399 fits seamlessly into existing X86 industrial chassis — no custom brackets, no redesign, no integration headaches.

• 5 Displays + HDMI Input — Visual Flexibility: From 4K HDMI output to LVDS, eDP, MIPI-DSI, and VGA — plus HDMI input for video capture. Support virtually any display configuration for industrial HMI, medical imaging, and multi-screen control systems.

• Complete Connectivity Suite: Dual GbE with PoE + Wi-Fi 6 + Bluetooth 5.0 + PCIe 4G/5G — wired, wireless, and cellular options for any deployment scenario. No external adapters needed.

• Built for the Long Haul: -20°C to 70°C temperature range, industrial-grade components, fanless design (with optional fan headers), and isolated serial ports — engineered for years of reliable service in demanding industrial environments.

• Delivery & Packaging

  Item	Details
  Packaging	Anti-static bag + foam padding + industrial carton
  MOQ	1 piece (sample order), 100+ for volume pricing
  Lead Time	3–5 working days for samples; 15–20 working days for bulk orders
  Shipping	DHL, FedEx, UPS, or by sea (customer's choice)
