JP151 5-Inch Vertical Screen Dual-Lens Wide Dynamic Camera with Card Swiping Function for Attendance Management
JP151 5-Inch Vertical Screen Dual-Lens Wide Dynamic Camera with Card Swiping Function for Attendance Management
JP151 5-Inch Vertical Screen Dual-Lens Wide Dynamic Camera with Card Swiping Function for Attendance Management
JP151 5-Inch Vertical Screen Dual-Lens Wide Dynamic Camera with Card Swiping Function for Attendance Management
JP151 5-Inch Vertical Screen Dual-Lens Wide Dynamic Camera with Card Swiping Function for Attendance Management
JP151 5-Inch Vertical Screen Dual-Lens Wide Dynamic Camera with Card Swiping Function for Attendance Management
JP151 5-Inch Vertical Screen Dual-Lens Wide Dynamic Camera with Card Swiping Function for Attendance Management
JP151 5-Inch Vertical Screen Dual-Lens Wide Dynamic Camera with Card Swiping Function for Attendance Management
JP151 5-Inch Vertical Screen Dual-Lens Wide Dynamic Camera with Card Swiping Function for Attendance Management
JP151 5-Inch Vertical Screen Dual-Lens Wide Dynamic Camera with Card Swiping Function for Attendance Management
JP151 5-Inch Vertical Screen Dual-Lens Wide Dynamic Camera with Card Swiping Function for Attendance Management
JP151 5-Inch Vertical Screen Dual-Lens Wide Dynamic Camera with Card Swiping Function for Attendance Management
Specifications
Brand Name :
Shi Zun
Model Number :
JP151
Place of Origin :
China
MOQ :
Negotiable
Price :
Negotiable
Supply Ability :
100+pcs+day
Delivery Time :
10 working days
Packaging Details :
5 inches
Payment Terms :
T/T
Operating System :
SH518, 32-bit RISC CPU, Linux system
Performance :
Main frequency: 816MHz, built-in convolutional neural network acceleration NPU, 0.6T computing power
operating system :
RK3288 quad-core processor with 1.8GHz clock
Configuration :
RAM: 256MB DDR3L / Storage: 8GB EMMC
Screen Size :
5 inches
Screen Resolution :
480×854
Touch Screen :
10-point capacitive touch
Brightness :
250cd
Camera :
Dual infrared light + RGB camera (850nm), 2MP resolution, built-in high-performance ISP, automatic light adjustment for optimal performance
Record Storage :
Local storage supports up to 200,000 records
Speaker :
3W dual speakers with clear voice broadcast
Facial Algorithm :
Multi-feature dynamic recognition algorithm for faces and anti-spoofing defense Detection against photos, videos, masks, and printed materials; supports non-cooperation detection Capacity: 2000 face photos, 100,000 offline recognition logs, and a recogniti
Application Software :
Supports individual or group scheduling and attendance settings Management functions include access control via facial recognition, attendance, law enforcement records, and more
Operating Parameters :
Power Input: DC 12V, 2A Operating Temperature: -10°C to 60°C Humidity: 10%-90%
External Interfaces :
3 ports: 1 TTL, 1 RS485, 1 RJ45 standard network port Supports peripheral access such as electric locks
Appearance :
Front panel: Tempered glass Housing: CNC aluminum alloy material Installation: Wall-mounted Color: Black + Silver
Mechanism :
Electric lock and magnetic lock supported for access control based on successful facial recognition
Network Upload :
Supports server-based software for real-time data synchronization, storage, and summary reporting
Description

JP151 5-Inch Vertical Screen Dual-Lens Wide Dynamic Camera with Card Swiping Function for Attendance Management

5-inch All-in-one Attendance Device​ Introduction:

This product is a 5-inch all-in-one attendance device designed primarily for facial recognition attendance in factories, enterprises, and organizations. It can operate as a standalone unit or be networked for centralized management.

Features:
● Easy installation: simply connect to a power source and a network cable or WiFi.
● Facial photos can be enrolled directly on the device or uploaded through the backend system.
● Customizable voice prompts for terminal announcements.
● Comprehensive attendance management features in the backend system: supports grouping, scheduling, multiple clock-in times, automatic clock-out, attendance statistics, and Excel export.

5-inch All-in-one Attendance Device Parameters:

Operating System: SH518, 32-bit RISC CPU, Linux system Main frequency: 816MHz
NPU: 0.6T computing power Memory: 256MB DDR3L
Storage: 8GB EMMC Screen Resolution: 480×854
Camera: Dual infrared light + RGB camera (850nm), 2MP resolution, built-in high-performance ISP, automatic light adjustment for optimal performance Record Storage: Local storage supports up to 200,000 records
Speaker: 3W dual speakers with clear voice broadcast Power Input: DC 12V, 2A
External Interfaces: 3 ports: 1 TTL, 1 RS485, 1 RJ45 standard network port Installation: Wall-mounted

JP151 5-Inch Vertical Screen Dual-Lens Wide Dynamic Camera with Card Swiping Function for Attendance ManagementJP151 5-Inch Vertical Screen Dual-Lens Wide Dynamic Camera with Card Swiping Function for Attendance ManagementJP151 5-Inch Vertical Screen Dual-Lens Wide Dynamic Camera with Card Swiping Function for Attendance ManagementJP151 5-Inch Vertical Screen Dual-Lens Wide Dynamic Camera with Card Swiping Function for Attendance ManagementJP151 5-Inch Vertical Screen Dual-Lens Wide Dynamic Camera with Card Swiping Function for Attendance Management
