TDD-5 Digital Repeater Compass with 0.1° Accuracy, 24V DC Power, and RS422/RS232 Interface for Ship Navigation
TDD-5 Digital Repeater Compass with 0.1° Accuracy, 24V DC Power, and RS422/RS232 Interface for Ship Navigation
Specifications
Brand Name :
Navioptics
Model Number :
TDD-5
Certification :
CCS
Place of Origin :
China
MOQ :
1
Payment Terms :
T/T
Dimensions :
Shown in the outline dimension drawing
Weight :
About 1 KG
Reading Accuracy :
0.1°
Operating Temperature :
-15℃ ~ + 60℃
Voltage :
24V DC
Power Consumption :
about 6W
Description
TDD-5 Digital Repeater Compass
Product Overview

The TDD-5 Digital Repeater Compass is a modern repeater compass featuring compact design and flexible installation options including embedded, wall-mounted, or desktop configurations. This advanced instrument transmits the ship's heading data from the gyrocompass to any location on the vessel.

Utilizing the latest electronic and computer technologies, the repeater compass accurately determines bow and stern lines relative to geographical north, independent of the gyrocompass installation location.

The compass offers dual display modes: analog and digital, with adjustable illumination brightness controlled via front-panel buttons.

Technical Specifications
Specification Details
Dimensions As shown in outline dimension drawing
Weight Approximately 1 kg
Reading Accuracy 0.1°
Protection Level IP22
Operating Temperature -15℃ to +60℃
Voltage 24V DC
Power Consumption Approximately 6W
Heading Serial Interface RS422 or RS232 (NMEA)
RS422 Port 4800 baud, 1 start bit, 1 stop bit, no parity
Cycle Time 120 ms

NMEA Interface Compliance: Information transmission complies with NMEA0183 Version 2.00 (IEC 61162-1). Supported statements include:

  • $xxHDTxxx.x,T*cc<CR><CF>
  • $xxHDM,xxx.x,T*cc<CR><CF>
  • $xxHDGxxx.x,,*cc<CR><LF>

Where: xxx.x represents repeater compass heading value, *CC is hexadecimal check bit (00-FF), <CR> is Enter, and <CF> is Migration.

Dimension Drawing
TDD-5 Digital Repeater Compass with 0.1° Accuracy, 24V DC Power, and RS422/RS232 Interface for Ship Navigation
